WOODWARD 5441-693

WOODWARD 5441-693 Product Documentation

1.Product Overview

The WOODWARD 5441-693 is a discrete input/output(I/O)module designed for industrial automation and control systems.Engineered for seamless integration with programmable logic controllers(PLCs),it serves as a critical interface for managing digital signals in applications such as machinery control,power generation,and process automation.With 24 optically isolated digital inputs and 13 relay outputs,the module ensures reliable signal transmission and robust control over external devices.Its compact design(263×58×28 mm)and lightweight construction(4.3 kg)make it suitable for space-constrained environments.

2.Key Technical Parameters

Parameter Specification

Input Channels 24 optically isolated digital inputs

Output Channels 13 relay outputs

Update Time 5 ms

Time Stamping 1 ms resolution

Power Supply Isolated 24 VDC,400 mA max

Communication Interface port for PLC connectivity

Dimensions 263×58×28 mm

Weight 4.3 kg

Compatibility Woodward PLC systems

3.Advantages and Features

Optical Isolation:Protects against electrical noise and voltage spikes,enhancing system reliability.

Fast Response:5 ms update time and 1 ms time stamping enable real-time monitoring and precise control.

High Channel Density:Supports 24 inputs and 13 outputs in a single module,reducing space requirements.

Robust Design:Built for industrial environments with durable components and secure mounting(screw-fastened chassis).

4.Application Areas and Use Cases

Industrial Automation:Machine tool control,conveyor systems.

Energy:Power plant monitoring,turbine management.

Manufacturing:Assembly lines,quality control systems.

Case Study:A manufacturing plant integrated the 5441-693 to manage 24 sensor inputs and 13 actuator outputs in a robotic assembly line,improving process accuracy by 20%and reducing downtime due to signal interference.

5.Competitive Comparison

The 5441-693 distinguishes itself through:

Higher Channel Capacity:More inputs/outputs compared to standard discrete I/O modules.

Enhanced Isolation:Optical isolation ensures superior noise resistance.

Compact Form Factor:Space-efficient design for modern control cabinets.

6.Selection Recommendations

System Requirements:Match input/output counts to application needs.

Power Compatibility:Verify 24 VDC supply availability.

Expansion Needs:Consider modularity for future system upgrades.

7.Precautions

Installation:Ensure proper grounding and secure module fixation.

Maintenance:Regularly inspect relay contacts for wear.

Environment:Avoid exposure to extreme temperatures or humidity.

Shanxi Xinyeda International Trade Co.,Ltd.offers WOODWARD 5441-693 and automation solutions.Contact us for sales and technical support.

Note:All external links have been removed as requested.
