Description
VIBRO-METER VM600 ABE040 is a high-performance 19-inch 6U industrial rack designed as the backbone of the VM600 series Machinery Protection System (MPS) and Condition Monitoring System (CMS). Engineered for critical rotating machinery applications, this rack serves as the central hub for housing modules such as MPC4 (machinery protection cards), IOCN (I/O and communication modules), and CMC16 (condition monitoring cards), enabling real-time vibration analysis, fault detection, and process control in industries like power generation, oil & gas, and manufacturing.
The
VM600 ABE040 features a rugged aluminum construction with a
VME backplane that supports up to
16 slots for modular expansion, including power supplies, processing cards, and communication interfaces. It integrates dual
RPS6U rack power supplies (AC/DC input) for redundant operation, ensuring continuous system availability in harsh environments. The front panel includes LED indicators for power status, module health, and alarm conditions, while the rear panel provides screw terminals for signal connections and VME bus interfaces.
Key functionalities include:
- Modular Architecture: Supports up to 12 processing cards (e.g., MPC4, IOCN, CMC16) and 2 power supplies for scalable monitoring and control.
- Redundancy: Dual power inputs and hot-swappable modules minimize downtime during maintenance or upgrades.
- Environmental Resilience: Operates in temperatures from -25°C to 60°C (standard) and withstands vibrations up to 5 g (IEC 60068-2-6), making it suitable for offshore rigs and power plants.
- Safety Compliance: Available in versions compliant with CE, RoHS, and cCSAus standards for hazardous environments.
| Parameter |
Specification |
| Rack Type |
19-inch, 6U (16 slots) |
| Power Supply |
Dual RPS6U (24 VDC ±10% or 110/230 VAC), 330 W per supply |
| Input/Output |
VME bus (32/64-bit), RS-485, Ethernet (CPUR2/IOCR2 modules) |
| Operating Temperature |
-25°C to 60°C (standard), -40°C to 85°C (extended) |
| Dimensions |
482.6 mm (W) × 292.1 mm (H) × 406.4 mm (D) (19″ × 11.5″ × 16″) |
| Weight |
15 kg (33 lb) without modules |
| Certifications |
CE, RoHS, IEC 61000-4-2 (ESD), IEC 61000-4-4 (EFT), cCSAus |
VM600 ABE040
-
Scalability and Flexibility:
- Accommodates up to 16 modules for high-channel density applications (e.g., multi-bearing turbines).
- Example: A petrochemical plant integrated VM600 ABE040 with MPC4 and IOCN modules to monitor 48 vibration channels across compressors, reducing unplanned downtime by 40%.
-
Redundancy and Reliability:
- Dual power supplies and hot-swappable design ensure 99.99% system uptime.
- Built-in VME bus redundancy prevents single points of failure in mission-critical systems.
-
Advanced Signal Handling:
- Supports 51.2 kHz sampling rates and 16-bit ADC resolution for precise vibration analysis.
- DSP-based algorithms filter noise and detect early-stage faults like bearing wear or misalignment.
-
Ease of Integration:
- Native compatibility with Modbus TCP/RTU and PROFIBUS DP via CPUR2/IOCR2 modules eliminates the need for external gateways.
- Power Generation: Monitors steam turbines and generators in thermal and nuclear plants.
- Oil & Gas: Protects compressors, pumps, and offshore platforms from vibration-induced failures.
- Manufacturing: Enhances CNC machine tool reliability through predictive maintenance.
Case Study:
A wind farm deployed VM600 ABE040 with CMC16 cards to monitor gearbox vibrations in 20 turbines. The system detected a gear tooth crack 72 hours before failure, saving $500,000 in repair costs.
| Feature |
VM600 ABE040 |
Typical Competitors |
| Slots |
16 |
8–12 |
| Temperature Range |
-25°C to 60°C |
0°C to 50°C |
| Redundancy |
Built-in dual power supplies |
Optional add-ons |
| Vibration Resistance |
5 g (IEC 60068-2-6) |
2–3 g |
| Integration |
Native MODBUS/PROFIBUS support |
Requires additional modules |
VM600 ABE040
- Channel Requirements:
- Choose VM600 ABE040 for applications needing 12+ modules (e.g., large turbines).
- Redundancy Needs:
- Opt for dual power supplies in critical environments (e.g., offshore platforms).
- Communication:
- Pair with CPUR2/IOCR2 modules for seamless integration with DCS/PLC systems.
- Environmental Conditions:
- Select the extended temperature version (-40°C to 85°C) for extreme climates.
-
Installation:
- Use anti-static wrist straps to avoid ESD damage.
- Ensure proper grounding and shielded cables to minimize EMI interference.
-
Operation:
- Do not exceed input voltage limits (24 VDC ±10% or 110/230 VAC).
- Monitor front-panel LEDs for module faults or signal anomalies.
-
Maintenance:
- Clean cooling vents quarterly to prevent overheating.
- Update firmware via VIBRO-METER’s official channels for security patches.
Shanxi Xinyeda International Trade Co., Ltd. is your trusted partner for VM600 ABE040 and other automation spare parts. Visit our website www.xydcontrol.com or contact us for sales and technical support.
