TRICONEX 9563-810 External Termination Panel Detailed Explanation

Product Overview

The TriconeX 9563-810 external termination panel is an auxiliary device designed specifically for the Triconex safety instrumented system,primarily used to connect and manage external wiring of digital input modules.It provides a safe,reliable,and easy to maintain platform to connect the signals of on-site devices with the Triconex system.

9563-810 TRICONEX

Product Features

Safe and reliable:Designed to comply with relevant safety standards,ensuring the safety of system operation.

Easy to maintain:Modular design for easy installation and maintenance.

Strong compatibility:Designed specifically for Triconex digital input modules,with good compatibility.

Strong anti-interference ability:using high-quality materials and design,effectively suppressing external interference.

Product parameters and specifications

Type:Digital Input Terminal Panel

Number of channels:16 input points

Leakage current:maximum 3.3mA,typical value 2.5mA

Protection level:Depending on the specific model and application environment

Installation method:DIN rail installation

9563-810 TRICONEX

Product series and features

Triconex series:part of Honeywell’s Triconex series safety instrumented systems

Modular design:easy to use in combination with other Triconex modules

Strong universality:can be used for multiple types of Triconex digital input modules

Product function and purpose

The main function of the TRICONEX 9563-810 external termination panel is to:

Connection management:Connect the digital signals of on-site devices to the Triconex digital input module.

Signal isolation:Provides electrical isolation to protect the system from external interference.

Fault indication:Each input point is protected by a fuse and has a fuse indication.

9563-810 TRICONEX

application area

The TRICONEX 9563-810 external termination panel is widely used in various industrial fields,such as:

Petrochemical industry:Connect digital signal equipment such as limit switches and proximity switches.

Power industry:Connect digital signal equipment such as relays and switches.

Chemical industry:Connect various digital signal devices such as sensors and switches.

Metallurgical industry:Connect digital signal equipment such as limit switches and proximity switches.

summary

The TriconeX 9563-810 external termination panel is an essential part of the Triconex safety instrumented system,providing reliable external connections and signal management for the system.
