TRICONEX 2000417

Description

1. Product Description

2. Product Parameters

Parameter	Specification
Module Type	Terminal Block Module
Connection Type	Screw-type terminals (16 positions)
Voltage Rating	250V AC/DC
Current Rating	10A per terminal
Wire Gauge Compatibility	22 AWG to 12 AWG (solid/stranded copper)
Material	Flame-retardant plastic housing, nickel-plated copper contacts
Operating Temperature	-40°C to +85°C
Dimensions	100 mm (H) x 50 mm (W) x 75 mm (D)
Certifications	CE, RoHS, IEC 61010-1

TRICONEX 2000417

3. Advantages and Features

• Rugged Design: The 2000417 features a durable, flame-retardant housing and corrosion-resistant nickel-plated contacts, ensuring long-term reliability in harsh conditions. Its sealed construction protects against dust, moisture, and mechanical damage.
• Easy Installation: The module’s standardized screw-terminal layout and color-coded labeling simplify wiring and reduce installation errors. It supports quick removal and replacement for maintenance without disrupting adjacent connections.
• High-Density Termination: With 16 independent terminals, the 2000417 optimizes space in control panels, allowing compact yet flexible system designs.
• Signal Integrity: Low-resistance contacts and shielded terminal blocks minimize voltage drop and electromagnetic interference (EMI), ensuring accurate signal transmission for critical control and safety systems.

4. Application Areas and Cases

• Application Areas: Used in industrial control panels, safety instrumented systems (SIS), and distributed control systems (DCS) across industries such as:
  • Oil & gas production (wellhead control, pipeline monitoring)
  • Power plants (turbine control, switchgear interfaces)
  • Manufacturing (robotics, conveyor systems)
• Application Case: A large petrochemical plant integrated the Triconex 2000417 into its emergency shutdown (ESD) system to terminate signals from pressure sensors and shutdown valves. The module’s robust design prevented connection failures during a severe storm, maintaining uninterrupted ESD functionality. Post-installation, the plant reported a 40% reduction in maintenance time for signal connections, attributed to the module’s user-friendly terminal layout and durability.

5. Comparison with Similar Products

Compared to generic terminal block modules, the 2000417 offers superior environmental resilience (e.g., wider temperature range and corrosion resistance) and safety certifications (CE, RoHS), making it suitable for regulated industries. Its compatibility with Triconex’s modular control systems ensures seamless integration, unlike non-branded alternatives that may require custom adapters or face compatibility issues.

TRICONEX 2000417

6. Selection Advice

• Voltage/Current Requirements: Ensure the module’s ratings match your system’s power and signal levels to avoid overload or signal degradation.
• Wire Gauge Compatibility: Verify that the terminal block supports the wire sizes used in your application, especially for high-power or low-voltage signals.
• Panel Space: Evaluate the module’s dimensions and terminal density to optimize control panel layout, particularly in space-constrained environments.

7. Precautions

• Wiring Procedures: Use appropriate torque specifications when tightening screw terminals to prevent wire damage or loose connections. Avoid overloading terminals beyond the rated current.
• Environmental Protection: Install the module in a properly sealed control panel if deployed in extremely humid, dusty, or corrosive environments to extend lifespan.
• System Grounding: Ensure proper grounding of the terminal block and control panel to mitigate EMI and static discharge risks.
