SCHNEIDER 140DDI35300

Description

SCHNEIDER 140DDI35300

SCHNEIDER 140DDI35300 Product Description:

The SCHNEIDER 140DDI35300 is a digital input module for industrial automation control systems,mainly used to receive and process digital signals from field equipment(such as switches,sensors,etc.).

Product parameters:

Input channels:32 discrete inputs.

Input voltage range:24V DC,support wide voltage range(19.2-30V DC).

Input current range:≥2mA.

Input response time:<1ms.

Operating temperature range:-40℃~+70℃.

Power consumption:1.7W+(0.36x number of channels in state 1).

Size:120mm×70mm×90mm,weight:250g.

SCHNEIDER 140DDI35300

Product Specifications:

The module adopts packet isolation and sink logic circuit,which enhances its security and stability.

The module has overvoltage protection function to ensure stable operation in the case of abnormal voltage.

The module supports online configuration and modification,which is easy for users to use.

Series:

It belongs to the Modicon Quantum series.

Features:

High reliability:The technology and design of Schneider Electric ensure the reliability and stability of the module.

Multiple input types:Support different types of discrete inputs,such as switching signals,photoelectric sensors,etc.

Easy to expand:The number of input channels can be increased through the expansion module to meet the needs of different scale applications.

Strong compatibility:Compatible with other PLC modules and controllers for easy system integration.

Functions:

It is used to receive and process digital signals from various input devices,such as switches,sensors and limit switches.

SCHNEIDER 140DDI35300

SCHNEIDER 140DDI35300

Purpose:

It is suitable for data acquisition and control in industrial automation control system.

Application field:

Widely used in power,chemical,machinery and other fields of automatic control system,can effectively detect the input signal and carry out the corresponding control operation.In addition,it is also suitable for power plant DCS monitoring system,intelligent flat tempering furnace system manufacturing,PLC programmable conveying control system and other fields.
