HIMA X-AO1601 16-Channel Analog Output Module

1. Product Description

• Wide Signal Range: Accommodates diverse actuators, including control valves, variable frequency drives (VFDs), and proportional solenoids.
• High-Speed Control: Processes signals at 1 kHz, enabling real-time adjustments in dynamic systems.
• Modular Compatibility: Integrates with HIMA’s HIMax safety systems and third-party PLCs via PROFIBUS DP or Modbus RTU.
• Hot-Swap Capability: Allows maintenance without system shutdown, minimizing downtime in 24/7 operations.

2. Technical Parameters

Parameter	Specification
Brand	HIMA
Model	X-AO1601
Module Type	16-channel analog output (SIL 3)
Output Types	Current (4–20 mA) or voltage (0–10 V)
Resolution	16-bit
Accuracy	±0.1% F.S.
Update Rate	1 kHz
Safety Integrity Level	SIL 3 (IEC 61508), TÜV-certified
Power Supply	24 V DC ±15% (external) / 5 V DC (internal)
Operating Temperature	-20°C to +60°C (industrial)
Protection Class	IP20 (dust protection)
Dimensions	120 mm × 50 mm × 25 mm
Weight	200 g
Certifications	CE, UL, cUL, NEC Class 1 Div 2

HIMA X-AO1601

3. Advantages and Features

• Safety-Critical Performance:
  The X-AO1601’s SIL 3 certification ensures compliance with the highest safety standards, making it suitable for applications where failure could lead to catastrophic consequences. Its redundant processors and self-diagnostic functions—such as DAC linearity checks and cross-talk detection—minimize undetected faults, achieving a diagnostic coverage rate of 99%.
• Precision and Flexibility:
  With 16-bit resolution and ±0.1% accuracy, the module delivers precise control for critical processes. It supports both current and voltage outputs, eliminating the need for external signal conditioning and reducing installation complexity.
• Environmental Robustness:
  The module operates reliably in extreme temperatures (-20°C to +60°C) and withstands high humidity and vibration. This makes it ideal for harsh environments such as offshore platforms, chemical plants, and manufacturing facilities with fluctuating conditions.
• Scalability:
  As part of HIMA’s modular HIMax system, the X-AO1601 allows easy expansion of I/O channels, making it suitable for both small-scale setups and large industrial projects.

4. Application Areas and Case Study

Application Areas:

• Oil & Gas: Controlling valve positions in wellheads, pipelines, and refineries to ensure safe and efficient operations.
• Chemical Processing: Managing reactor parameters, such as temperature and pressure, through proportional control valves.
• Power Generation: Optimizing turbine efficiency and balancing generator loads in power plants.
• Manufacturing: Enabling precise motion control in automotive and pharmaceutical production lines.

Case Study:

5. Competitive Comparison

• Superior Safety Certification: SIL 3 compliance exceeds many alternatives that offer only SIL 2, making it a preferred choice for high-risk applications.
• Extended Temperature Range: The ability to operate up to +60°C ensures reliability in environments where other modules might fail due to heat stress.
• Integrated Diagnostic Tools: Advanced self-tests and 99% fault coverage reduce the risk of undetected errors, outperforming modules with basic diagnostic capabilities.
• Versatile Signal Support: Native compatibility with both current and voltage outputs eliminates the need for additional hardware, simplifying system design and reducing costs.


  HIMA X-AO1601

6. Selection Recommendations

• Safety Requirements: Prioritize the X-AO1601 if your application requires SIL 3 certification, such as in processes governed by IEC 61511 standards.
• Signal Compatibility: Confirm that the module supports your actuator’s input type (current or voltage) and ensure the 16-bit resolution meets your precision needs.
• Environmental Conditions: Choose the module if your environment falls within the -20°C to +60°C range, such as outdoor or high-temperature sites.
• System Scalability: Evaluate if the 16-channel configuration aligns with your current I/O requirements, and consider HIMA’s modular expansion options for future upgrades.

7. Precautions

• Installation:
  • Use shielded cables to minimize EMI interference and route power and signal cables separately to avoid noise coupling.
  • Torque terminal screws to the recommended 1.2 N·m to ensure secure connections and prevent loose wiring.
• Configuration:
  • Program the module using HIMA’s HIMax Workbench software, verifying signal ranges, scaling factors, and safety parameters.
  • Regularly back up configuration files to protect against data loss during firmware updates or hardware replacement.
• Maintenance:
  • Inspect the module quarterly for physical damage or loose connections, especially in high-vibration environments.
  • Replace the module every 10 years or after 1 million operating cycles (whichever comes first) to maintain optimal performance.
• Safety Compliance:
  • Adhere to IEC 61511 guidelines when designing safety instrumented systems, ensuring the module is part of a properly validated and tested architecture.
  • Avoid using non-certified modules alongside the X-AO1601 to maintain overall system safety integrity.

Shanxi Xinyeda International Trading Co., Ltd. is your trusted partner, we provide and other automation spare parts sales and technical support. Please visit our website www.xydcontrol.com or contact us and we will be happy to serve you.
