HIMA F6217

Description

Lead marking cable plug to connect current/
Lead marking cable plug to connect voltage via
voltage Z 7127 1 62171 C..11(U5V)
potentiometer and smart transmitters
Z 7127 16217 1C..1/ U10V
Figure 2: Lead marking cable plug
The module contains a redundant, safety-related processor system. Because of this, all the
tests are executed directly on the module. The main test routines are:
一Linearity of the A/D converters
一Overflow of the A/D converters
一Cross talking between the eight input channels
Function of the input filters
– Function of the I/O bus communication
Flat pin plug 6.3 x 0.8 mm, to be connected to the earth bar under the slot
Lead marking cable plug with transmitter supply Z 71281 6217 1C../ITI
Figure 9: Lead marking cable plug with transmitter supply
Cable plugs marked with R1 and R2 are for redundant systems, applications refer to previous
figures.
If using the transmitter Saab/Rosemount 3300 GWR with internal zener diode a galvanic iso-
lation in the signal connection must be provided to remove interferences (signal spikes, unde-
fined signal levels) at the analog inputs of the F 6217.
Therefore e.g. the analog isolator with HART H 6200 of HIMA can be used.
