HIMA F3 DIO 8/8 01

Description

HIMA F3 DIO 8/8 01DescriptionRemote I/O (8 digital inputs, 8 digital outputs, 2 pulsed outputs),Operating temperature: 0…+60 °C,for ELOP II Factory programming toolRemote I/O (8 digital inputs, 8 digital outputs, 2 pulsed outputs),Operating temperature: -25…+70 °C (temperature class T1),Vibration and shock tested according to EN 50125-3 and EN 50155,class 1B according to IEC 61373,for ELOP II Factory programming toolRemote I/O (8 digital inputs, 8 digital outputs, 2 pulsed outputs),Operating temperature: 0…+60 °C,for SILworX programming toolRemote I/O (8 digital inputs, 8 digital outputs, 2 pulsed outputs),Operating temperature: -25…+70 °C (temperature class T1)

The safety-related F3 DIO 8/8 01 remote I/O is a compact system in a metal enclosure with
8 digital inputs, 8 digital DO+ outputs (L- ground), 2 digital DO- outputs (S+ ground) and 2
pulsed outputs. The digital outputs DO4+, DO8+, DO4- and DO8- can also be connected as
two-pole connections.
The remote I/O is available in a model variant for SILworX and a model variant for ELOP II
Factory, see Chapter 3.2. All variants are described in this manual.
The remote I/O serves to extend the I/O level of HIMax and HIMatrix controllers, and is
connected to them via safeethernet. The remote I/O itself is not able to run a user program.
The HIMatrix remote I/Os are not multi-master capable
