VMIVME-3125

Description

GE VMIVME-3125 A/D Conversion Module Product Overview

Product Overview

GE VMIVME-3125 is a high-performance VME bus analog-to-digital conversion(ADC)module primarily used to convert analog signals into digital signals for processing and analysis by computer systems.It is widely used in industrial control,data acquisition,testing and measurement fields.

VMIVME-3125 GE

main features

High resolution:A 12 bit ADC provides high-precision data conversion.

Multi channel:Supports 32 single ended or 16 differential input channels,capable of simultaneously collecting multiple analog signals.

Flexible configuration:Parameters such as gain and input range can be configured through jumper cables to adapt to different application scenarios.

VME bus interface:Complies with the VME bus standard and can be flexibly assembled with other VME modules.

High reliability:Designed for industrial environments,it has high stability and anti-interference ability.

Product parameters

ADC resolution:12 bits

Number of input channels:32 single ended or 16 differential

Input range:optional,such as±5V,±10V,0~10V

Sampling rate:40kHz

Gain:optional,such as x1,x10,100x

Bus:VME

Product specifications

Size:Board size that meets VME standards

Working temperature:0°C~55°C

VMIVME-3125 GE

Product series

VMIVME-3125 belongs to the VME series products of VMIC(now Abaco Systems)and is typically used in conjunction with industrial control systems from General Electric(GE).

Product function

Data collection:used to collect various analog signals,such as temperature,pressure,voltage,etc.

Testing and Measurement:Used for various testing and measurement systems,such as electronic testing,instrumentation,etc.

Industrial automation:used in industrial process control systems to collect process variables.

application area

Industrial Automation:Factory Automation,Process Control

Aerospace:Flight Data Collection

Testing and measurement:electronic testing,instrumentation

Medical equipment:physiological signal acquisition

VMIVME-3125 GE

summary

GE VMIVME-3125 is a powerful and flexible A/D conversion module suitable for various applications that require the conversion of analog signals to digital signals.
