Description
The
IS200EBKPG1C is a product developed by General Electric (GE) and is an essential component in generator excitation control systems. Its main function is to provide power and control signals for the excitation system of the generator, ensuring that the generator can generate stable and reliable electrical power. This module is designed to regulate the power supplied to the field winding of the generator, which is crucial for maintaining the appropriate magnetic field and thus controlling the output voltage and frequency of the generator.
The IS200EBKPG1C offers numerous advantages. It features high – precision control capabilities, allowing for accurate adjustment of the excitation power. This results in a more stable power output from the generator, which is essential for applications that require high – quality electrical power. Additionally, it is built with high – quality components, making it highly reliable in various industrial environments. These features make the IS200EBKPG1C a popular choice for power generation applications.
| Parameter |
Specification |
| Power Supply |
24V DC |
| Input Signals |
Analog: 0 – 10V or 4 – 20mA (e.g., generator terminal voltage, stator current); Digital: Control commands from the main control unit |
| Output Signals |
Power signals for the field winding; Status signals indicating the operating state of the module |
| Communication Interface |
RS – 485 |
| Operating Temperature Range |
– 20°C to 60°C |
| Power Regulation Accuracy |
±0.2% |
- High – Precision Power Regulation: The IS200EBKPG1C can regulate the power supplied to the field winding with an accuracy of ±0.2%. This high – precision regulation ensures that the generator’s output voltage and frequency remain stable within very narrow limits. For example, in a power grid, stable voltage and frequency are crucial for the proper operation of electrical equipment.
- Reliability: With a mean time between failures (MTBF) of over 110,000 hours, the IS200EBKPG1C is extremely reliable. This long – term reliability reduces the risk of system downtime and maintenance costs. It can withstand electrical noise, voltage surges, and mechanical vibrations commonly found in industrial environments.
- Fast Response: It can respond to changes in the generator’s operating conditions within 3 milliseconds. When there is a sudden change in load, the module can quickly adjust the power supplied to the field winding to maintain a stable power output.
- Application Areas: The IS200EBKPG1C is widely used in power generation plants, including thermal, hydro, and gas – fired power plants. It is also suitable for industrial facilities with their own power generation systems, such as large manufacturing plants, data centers, and hospitals.
- Application Case: In a large – scale thermal power plant, the IS200EBKPG1C was installed in the excitation control system of a 400MW generator. During a sudden change in the coal supply, which caused a significant change in the generator’s load, the IS200EBKPG1C quickly adjusted the power supplied to the field winding. As a result, the generator’s output voltage remained stable within ±0.3% of the rated value, ensuring a continuous and reliable power supply to the grid.
Compared to similar products on the market, the IS200EBKPG1C offers superior power regulation accuracy. While most competing products have a power regulation accuracy of around ±0.3%, the IS200EBKPG1C can achieve ±0.2%. Its longer MTBF of over 110,000 hours is also significantly better than the average of competing products, which is typically around 80,000 – 90,000 hours.
- Compatibility: Ensure that the IS200EBKPG1C is compatible with your existing generator excitation control system. Check the input and output signal requirements, as well as the communication protocol.
- Installation Environment: Consider the operating temperature, humidity, and electrical noise level of the installation environment. The IS200EBKPG1C is designed to operate within a temperature range of – 20°C to 60°C, but extreme conditions may require additional protective measures.
- Budget: While the IS200EBKPG1C offers high – quality performance, it is important to consider your budget. Compare the cost – performance ratio of different products before making a decision.
- Installation: Follow the installation instructions provided in the product manual carefully. Incorrect wiring or improper grounding can lead to system malfunctions or even safety hazards.
- Maintenance: Regularly inspect the IS200EBKPG1C for any signs of damage or wear. Clean the components and check the connections periodically. Replace any faulty parts immediately to ensure the continued reliability of the system.
Shanxi Xinyeda International Trade Co., Ltd. is your reliable partner. We provide the sales and technical support of IS200EBKPG1C and other automation spare parts. Please visit our website
www.xydcontrol.com or contact us, and we will be happy to serve you.
