GE Fanuc IC698CMX016 Product Specification
IC698CMX016 is a high-performance communication module developed by GE Fanuc, a leading provider of automation solutions. This module is designed to enable secure and efficient data exchange in industrial control systems, supporting advanced protocols and redundancy features for mission-critical applications.
The
IC698CMX016 serves as a vital component in GE Fanuc’s Series 90-70/30 PLC platforms, facilitating seamless integration between field devices, HMIs, and supervisory systems. It supports multiple communication protocols, including Ethernet/IP, Modbus, and Profibus, making it adaptable to diverse industrial environments. With its dual-port redundancy and robust EMI shielding, the module ensures continuous operation in harsh conditions, such as automotive manufacturing, chemical processing, and power generation.
| Parameter |
Specification |
| Communication Protocols |
Ethernet/IP, Modbus RTU, Profibus DP |
| Redundancy Support |
Dual-port network redundancy |
| Data Rate |
Up to 100 Mbps |
| Voltage Range |
24V DC ±15% |
| Interfaces |
RJ45, RS-485 |
| Operating Temperature |
-40°C to 70°C |
| Certifications |
CE, UL, IEC 61000-6-2/-6-4 |
IC698CMX016
- Dual-Port Redundancy: Ensures uninterrupted communication by automatically switching to a backup network in case of failure.
- Multi-Protocol Support: Reduces the need for additional gateways, simplifying system architecture.
- High-Speed Performance: Enables real-time data processing for dynamic control applications.
- Compact Design: Fits into space-constrained control cabinets while maintaining industrial-grade durability.
IC698CMX016 is widely used in:
- Automotive Manufacturing: Coordinating robotic welding systems and conveyor networks.
- Water/Wastewater Treatment: Monitoring pump stations and SCADA integration.
- Oil and Gas: Controlling offshore drilling platforms and pipeline monitoring systems.
Case Study: A steel mill in Brazil implemented the IC698CMX016 to connect 80+ sensors and actuators, achieving a 30% reduction in system downtime and improving production efficiency by 15%.
The IC698CMX016 outperforms comparable modules through:
- Faster redundancy recovery (≤30ms vs. industry average of 80ms).
- Built-in cybersecurity features, including advanced encryption for data protection.
- Support for legacy protocols alongside modern Ethernet standards, minimizing upgrade costs.
IC698CMX016
- Compatibility: Ensure compatibility with your existing GE Fanuc PLC model and network infrastructure.
- Protocol Requirements: Verify support for the specific communication standards used in your application.
- Scalability: Consider future expansion needs when selecting the number of ports.
- Avoid exposing the module to direct sunlight or extreme humidity.
- Use shielded cables to prevent signal interference.
- Regularly test redundant network paths to ensure failover functionality.
Shanxi Xinyeda International Trading Co., Ltd. is your trusted partner for
IC698CMX016 and other GE Fanuc automation spare parts. Visit
www.xydcontrol.com or contact us for sales and technical support.
Full 12-month warranty
Available for dispatch immediately
We deliver worldwide
Full 12-month warranty on all components
