Product Description: GE Fanuc IC693CPU363 Series 90-30 CPU Module

The GE Fanuc IC693CPU363 is a high-performance single-slot CPU module designed for industrial automation, part of the Series 90-30 PLC family. Equipped with a 25 MHz 80386EX processor and 240 KB configurable user memory, the IC693CPU363 delivers advanced control capabilities for complex logic, high-speed data processing, and multi-protocol communication. Its three built-in serial ports (RS232/RS485) and support for protocols like Ethernet, Profibus, and FIP enable seamless integration with HMIs, SCADA systems, and remote I/O modules. Ideal for harsh environments (0–60°C operation), the module features flash memory for firmware updates, battery-backed real-time clock, and floating-point math support (via firmware v9.0+), making it suitable for manufacturing, energy, and process control applications.

Product Parameters

Parameter Specification
Processor 80386EX, 25 MHz
Memory 240 KB user memory (configurable for %R, %AI, %AQ; 28-word system registers)
I/O Capacity 2,048 discrete inputs/outputs; up to 8 baseplates (1 local + 7 remote/expansion)
Communication 3 serial ports (RS232/RS485): 2 front-panel (RJ45/15-pin sub-D), 1 via power supply (SNP/SNP-X slave). Optional Ethernet/Profibus modules.
Power Supply +5 VDC, 890 mA
Operating Temperature 0–60°C (32–140°F); storage: -40–85°C
Scan Rate 0.22 ms/kB (boolean logic)
Memory Storage RAM + Flash (firmware upgradable)
Floating-Point Math Firmware-based (v9.0+)
Expansion Support 7 remote/expansion baseplates
IC693CPU363

IC693CPU363

Advantages and Features

  1. Multi-Protocol Connectivity: Three serial ports (2 front-panel, 1 power-supply) support SNP/SNP-X, RTU, and legacy GE protocols, reducing hardware costs.
  2. Flexible Memory Configuration: 240 KB user memory configurable via LogicMaster (16,384 words) or Control V2.2 (32,640 words) for complex applications.
  3. High Reliability: Industrial-grade design with wide temperature range and flash memory for firmware updates without EPROM replacement.
  4. Advanced Functions: Built-in PID, 高速计数器 (HSC), 脉宽调制 (PWM), and periodic subroutines for machine automation.
  5. Scalability: Supports up to 8 baseplates (2,048 I/O points) for distributed control systems.

Application Areas and Use Cases

  • Industries: Manufacturing, packaging, water treatment, and material handling.
  • 典型应用案例:
    A water treatment plant integrated the IC693CPU363 to manage pump systems and chemical dosing. Its three serial ports enabled simultaneous communication with sensors (RS485), HMIs (RS232), and a SCADA system (Ethernet module). The module’s 240 KB memory stored complex PID algorithms, reducing manual adjustments by 30% and improving process efficiency.

Competitor Comparison

Compared to similar CPUs (e.g., Allen-Bradley Micro830 or Siemens S7-1200):



  • Higher I/O Density: 2,048 points vs. ~256 in entry-level models.
  • Legacy Compatibility: Seamless integration with GE Fanuc Series 90-30 I/O (e.g., IC693MDL730, IC693PWR330H) and software.
  • Multi-Port Architecture: Three serial ports (vs. 1–2 in competitors) for concurrent device connectivity.
    IC693CPU363

    IC693CPU363

Selection Recommendations

  1. Compatibility: Ensure alignment with Series 90-30 baseplates (e.g., IC693CHS392) and I/O modules.
  2. Memory Requirements: Choose based on application complexity (e.g., 128–32,640 words for register memory).
  3. Communication Needs: Use optional Ethernet/Profibus modules for networked systems.
  4. Environment: Verify temperature/humidity conditions (0–60°C operation).

Precautions

  1. Power Stability: Use a regulated +5 VDC supply (890 mA max) to avoid voltage drops.
  2. Firmware Updates: Regularly update flash firmware via serial port for protocol support (e.g., floating-point math in v9.0+).
  3. Grounding: Connect frame ground to reduce EMI interference.
  4. Battery Replacement: Replace the clock battery (GE part 44A725214-001) every 5–7 years.
