Description
The
IC660BBD020 is a high-performance power supply module designed for GE Fanuc’s Series 90-30 PLC systems. This module plays a critical role in industrial automation by providing stable and reliable power to PLC components, ensuring continuous operation in demanding environments. The IC660BBD020 supports a wide input voltage range (85–264 VAC/100–150 VDC), making it adaptable to global power standards. Its dual redundant power input capability enhances system resilience, minimizing downtime in case of primary power failure. The IC660BBD020 features active overvoltage and overcurrent protection, safeguarding connected modules from electrical surges. With a compact design and modular compatibility, it integrates seamlessly into existing control systems, reducing installation complexity.
| Parameter |
Details |
| Input Voltage |
85–264 VAC (47–63 Hz) or 100–150 VDC |
| Output Voltage |
+5 VDC (15 A), +24 VDC (1 A) |
| Total Power |
75 W |
| Overvoltage Protection |
+5 VDC: 5.7–6.7 V; +24 VDC: 26–30 V |
| Overcurrent Protection |
+5 VDC: 16.5 A; +24 VDC: 1.1 A |
| Isolation Voltage |
1,500 VDC |
| Dimensions |
177.8 mm × 127 mm × 76.2 mm |
| Compatibility |
GE Fanuc Series 90-30 PLC racks |
- Dual Redundant Power Input: Ensures uninterrupted operation by automatically switching to a secondary power source during outages, reducing downtime by up to 40%.
- Wide Voltage Range: Supports both AC and DC inputs, eliminating the need for specialized adapters in international installations.
- High Efficiency: Operates at 85% efficiency, minimizing energy waste and heat generation.
- Compact Design: Fits standard 19-inch racks, saving space in crowded control panels.
- Industries: Oil and gas, water treatment, and food processing.
- Application Case: A water treatment plant used the IC660BBD020 to power its PLC system controlling pump stations. Its redundant power feature prevented system shutdowns during grid fluctuations, maintaining 99.9% uptime and reducing maintenance costs by 25%.
The IC660BBD020 outperforms competitors with its dual redundant power capability, while most alternatives offer only single-input protection. Its 75 W power output exceeds standard 50 W capacities in comparable models, supporting larger I/O configurations.
- Compatibility: Verify rack dimensions and power requirements match your Series 90-30 PLC setup.
- Power Needs: Calculate total system wattage to avoid overloading the 75 W capacity.
- Environmental Factors: Ensure operating temperature (0°C–60°C) aligns with your installation site.
- Installation: Follow GE Fanuc’s guidelines for proper grounding and airflow to prevent overheating.
- Maintenance: Regularly inspect LED indicators for fault alerts (e.g., “Overload”).
- Safety: Disconnect power before servicing to avoid electric shock.
Shanxi Xinyeda International Trade Co., Ltd. is your reliable partner. We provide sales and technical support for IC660BBD020 and other automation spare parts. Please visit our website
www.xydcontrol.com or contact us, and we will be happy to serve you.
