Description
1. Product OverviewThe
GE Fanuc DS200TCPDG1BBB is a high-reliability power distribution module designed for critical industrial control systems, particularly in GE’s Mark V turbine control platforms. As part of the DS200 series, this module ensures stable power supply management in harsh environments, supporting seamless integration with GE’s distributed control systems (DCS) and programmable logic controllers (PLCs). Its advanced architecture prioritizes safety, efficiency, and ease of maintenance, making it ideal for energy, manufacturing, and process automation sectors.
2. Key Technical Parameters
| Parameter |
Specification |
| Voltage Range |
24V DC ±10% |
| Rated Current |
20A |
| Output Channels |
8 (Relay Contacts) |
| Input Type |
Digital |
| Redundancy Support |
Dual-channel |
| Dimensions |
118 mm x 105 mm x 48 mm |
3. Advantages and Features
- Redundant Design: Dual-channel architecture minimizes downtime by ensuring continuous operation even if one channel fails.
- Self-Test Function: Built-in diagnostics monitor performance and alert operators to potential issues.
- Compact Size: Space-saving design simplifies installation in confined control panels.
- High Load Capacity: Handles up to 20A per channel for robust power distribution.
4. Application Areas and Use Cases
- Industry: Power generation, oil and gas, and heavy machinery.
- Function: Managing power distribution for steam turbines, auxiliary systems, and safety-critical processes.
- Case Study: A U.S. power plant upgraded its turbine control system with the DS200TCPDG1BBB, reducing maintenance costs by 20% and improving system uptime to 99.9%.
5. Competitor Comparison
Compared to similar modules, the DS200TCPDG1BBB offers superior redundancy and faster fault detection, ensuring compliance with stringent safety standards. Its compatibility with GE’s legacy and modern systems also reduces integration complexity.
6. Selection Recommendations
- System Compatibility: Verify integration with GE Mark V or compatible DCS/PLC systems.
- Load Requirements: Ensure the module’s current capacity matches your application’s peak demands.
- Environment: Consider temperature and vibration levels to avoid overheating or physical damage.
7. Precautions
- Installation: Use anti-static equipment to prevent ESD damage during handling.
- Maintenance: Regularly inspect connectors and replace worn components to maintain performance.
- Safety: Follow GE’s guidelines for power module replacement and system shutdown procedures.
Shanxi Xinyeda International Trade Co., Ltd. is your reliable partner. We provide sales and technical support for DS200TCTGG1ACA and other automation spare parts. Please visit our website
www.xydcontrol.com or contact us, and we will be happy to serve you.
