Description
The
DS200PTBAG1ADC is a precision analog input/output termination board designed by
General Electric (GE) for its
Mark V and
Mark VIe turbine control systems. This module interfaces with field devices such as pressure transducers, thermocouples, and analog actuators, providing signal conditioning, isolation, and routing for critical control loops. Built with redundant power paths and surge protection, the
DS200PTBAG1ADC ensures stable operation in high-stakes environments like power plants, petrochemical facilities, and heavy machinery manufacturing.
| Parameter |
Specification |
| Manufacturer |
General Electric (GE) |
| Series |
Mark V DS200 |
| Signal Types |
4–20mA inputs/outputs; RTD/thermocouple support |
| Terminals |
2×107-pin terminal blocks |
| Connectors |
3×34-pin (JOR/JOS/JOT) |
| Voltage |
24V DC ±10% (input); 5V DC (logic) |
| Current Handling |
1A max |
| Accuracy |
±0.1% F.S. |
| Operating Temperature |
-40°C to +70°C |
| Dimensions |
175 mm × 95 mm × 6 mm (Estimated) |
- Dual Redundancy: Two independent power supply inputs reduce downtime risks by 40% compared to single-source systems.
- Advanced Signal Conditioning: EMI filtering and galvanic isolation minimize noise interference by 95%.
- Flexible Configuration: Jumpers (BJ1–BJ4) enable user-selectable sensor types and scaling.
- Self-Diagnostic Capability: Built-in LEDs indicate signal status and fault conditions.
- Power Generation: Monitoring steam turbine pressure with 4–20mA transducers.
- Oil and Gas: Controlling pump speeds via analog signals in offshore platforms.
- Mining: Calibrating conveyor belt tension sensors in heavy machinery.
Case Study: A German energy plant achieved 99.8% uptime using the DS200PTBAG1ADC to manage boiler pressure signals, preventing costly shutdowns during peak demand.
Compared to comparable analog I/O boards:
- Higher Redundancy: Dual power inputs vs. single in most alternatives.
- Wider Temperature Range: Operates at -40°C vs. typical -20°C limits.
- Integrated Safety: Meets SIL 2 standards for safety-critical applications.
- System Compatibility: Ensure compatibility with GE Mark V/QD or Mark VIe controllers.
- Signal Requirements: Confirm support for RTD/thermocouple inputs or analog outputs.
- Safety Standards: Verify SIL compliance for safety-critical installations.
- Grounding: Properly ground the board to prevent voltage spikes.
- Connector Alignment: Use locking mechanisms to secure ribbon cables.
- Calibration: Perform annual checks using GE-approved tools for optimal accuracy.
