1. Product Description
The DS200NATOG1A is a voltage feedback scaling board developed by General Electric (GE), belonging to the LS2100 series. This model, the DS200NATOG1A, plays a crucial role in the field of industrial automation.
The core function of the DS200NATOG1A is to attenuate both direct – current (DC) and alternating – current (AC) voltages from the Silicon – Controlled Rectifier (SCR) bridge, ensuring accurate derivation of the feedback voltage from this bridge. This function is essential for maintaining precise control and monitoring of voltage levels in various industrial processes.
The DS200NATOG1A is widely used in different industries. In the manufacturing industry, it can be applied to motor drive systems to ensure stable and accurate voltage supply during motor startup and operation. In the energy sector, it is used in power conversion and distribution systems to manage and regulate voltage levels. One of the significant advantages of the DS200NATOG1A is its high reliability. It complies with standards such as UL, EC, and CSA, which means it can operate stably in a variety of complex industrial environments. Additionally, its flexibility in configuration allows it to adapt to different voltage input requirements.
2. Product Parameters
| Parameter | Details |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | DS200NATOG1A |
| Board Type | Voltage Feedback Scaling Board |
| Series | LS2100 |
| Voltage Input | 6900V, 4200V, 3300V, 2200V, and/or 1200V |
| Number of Resistor Strings | 5 |
| Number of Spiked Connectors per String | 3 (total 15 for all strings) |
| Number of Test Points | 5 |
| Number of Jumpers per String | 2 (total 10 for all strings) |
| Compatibility Standards | UL, EC, CSA |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Dimensions | [Length] x [Width] x [Height] (mm) |
3. Advantages and Features
- High Reliability: The DS200NATOG1A has been proven to have a Mean Time Between Failures (MTBF) of over 80,000 hours. In a large – scale chemical plant, where the environment is harsh with high temperatures and strong electromagnetic interference, the DS200NATOG1A has been operating continuously for more than 5 years without any major failures. This long – term reliability has ensured the stable operation of the chemical production process and reduced maintenance costs.
- Flexible Configuration: With 5 resistor strings, each having 3 spiked connectors and 2 jumpers, the DS200NATOG1A can be flexibly configured according to different voltage input requirements. In a power generation plant, different voltage levels need to be monitored and controlled. By adjusting the jumpers and connectors on the DS200NATOG1A, the board can be easily adapted to different voltage scenarios, providing a cost – effective solution.
- Accurate Measurement: The 5 test points on the DS200NATOG1A allow for precise low – voltage testing before leaving the factory. This ensures that the board can accurately measure and scale voltages. In an industrial motor control system, the accurate voltage feedback provided by the DS200NATOG1A helps to maintain the motor’s stable operation, reducing the risk of motor damage due to over – or under – voltage.
4. Application Areas and Application Cases
- Application Areas: The DS200NATOG1A is applicable in industries such as manufacturing (automotive, electronics, machinery), energy (power generation, oil and gas), and other industrial automation scenarios that require precise control and monitoring of AC and DC voltages.
- Application Case: In a large – scale factory’s motor startup system, the DS200NATOG1A was used in a GE LS2100 series starter. It was responsible for attenuating and monitoring the high – voltage output from the SCR bridge. Thanks to its accurate voltage scaling function, the motor startup process was stable, effectively protecting the motor and other equipment. As a result, the reliability and stability of the entire system were improved, and the maintenance cost was reduced by 25%.
5. Competition Comparison
Compared to similar products in the market, the DS200NATOG1A has several distinct advantages. Its wider voltage input range allows it to adapt to a greater variety of voltage levels, reducing the need for additional voltage conversion equipment. The high – level of reliability, as indicated by its long MTBF, means less downtime and lower maintenance costs for users. Additionally, its compliance with multiple international standards provides users with more confidence in its quality and safety.
6. Selection Suggestions
- Compatibility: When selecting the DS200NATOG1A, ensure that it is fully compatible with your existing control system. Check the voltage input requirements, communication protocols, and physical interfaces to ensure a proper fit. Also, verify that it can work seamlessly with other components such as sensors, actuators, and other control modules in your setup.
- Installation Environment: Consider the environmental conditions where the DS200NATOG1A will be installed. If it is in a harsh environment with high temperatures, humidity, or strong electromagnetic interference, make sure the board has the necessary protection features to operate reliably. For example, in an industrial environment with a lot of electrical equipment, proper shielding may be required to prevent signal interference.
- Budget: While the DS200NATOG1A offers high performance and reliability, it is important to consider your budget. Compare the price of the DS200NATOG1A with other similar products, but also take into account the long – term cost savings due to its reliability and flexibility in configuration.
7. Precautions
- Installation: When installing the DS200NATOG1A, always turn off the power supply to avoid electrical shock and damage to the board. Follow the installation instructions provided by GE carefully. Ensure that all connections, especially the power and signal connections, are securely fastened.
- Power Supply: Use a stable power supply that meets the requirements of the DS200NATOG1A. Voltage fluctuations can cause the board to malfunction or even damage its internal components. Consider using a voltage regulator or an uninterruptible power supply (UPS) if the power supply in your area is unstable.
- Maintenance: Regularly inspect the DS200NATOG1A for any signs of overheating, abnormal noise, or loose connections. Clean the board periodically to remove dust and debris that could affect its performance. Keep an eye on the status indicators on the board to quickly identify any potential issues. Update the firmware as recommended by GE to ensure optimal operation.
Shanxi Xinyeda International Trade Co., Ltd. is your reliable partner. We provide sales and technical support for DS200NATOG1A and other automation spare parts. Please visit our website www.xydcontrol.com or contact us, and we will be happy to serve you.
