Description
The GE Fanuc D20-EME 10BASE-T is a 10 Mbps Ethernet interface module designed for GE’s PACSystems RX3i platform, specialized in industrial automation and substation control. Engineered with a 32-bit PowerPC processor and D.20 HDLC communication ports, this module enables seamless integration of legacy systems with modern industrial networks, ensuring reliable operation in extreme environments.
The
D20-EME 10BASE-T serves as a critical component in GE’s PACSystems RX3i architecture, providing
10 Mbps Ethernet connectivity for real-time data exchange between PLCs, SCADA systems, and field devices. Its
D.20 HDLC protocol support allows direct communication with D20 I/O modules, while
7 RS-232/485 serial ports enable integration with legacy equipment like printers and IEDs. With
-40°C to +70°C operating range and
IP66/67 protection, the module withstands harsh conditions in power plants, oil refineries, and smart grid infrastructure.
| Parameter |
Specification |
| Communication |
10BASE-T Ethernet (IEEE 802.3), D.20 HDLC, RS-232/485 |
| Processor |
32-bit PowerPC MPC8548 (40 MHz) |
| Memory |
1.5 MB SRAM, 0.5 MB NVRAM, 2 MB Flash |
| Input Voltage |
110–240 VAC (50/60 Hz) or 110–370 VDC |
| Interfaces |
1× RJ45 (Ethernet), 7× RS-232/485 |
| Isolation |
2,500 VAC (channel-to-ground) |
| Dimensions |
178 mm × 140 mm × 64 mm (rack-mount) |
| Certifications |
CE, UL 508, IEC 61850 (substation automation) |
D20-EME
- Universal Protocol Support: Integrates D.20 HDLC for legacy systems and Ethernet/IP for modern networks, reducing retrofit costs by 30% in substation upgrades.
- Extreme Environment Resilience: Operates in -40°C to +70°C (vs. standard -20°C to +60°C), ideal for arctic or desert deployments.
- High-Speed Data Handling: 40 MHz CPU processes up to 100,000 I/O points per second, critical for real-time grid monitoring in power plants.
Case Study: A U.S. utility company reduced substation downtime by 45% using D20-EME 10BASE-T to monitor 16 240 VAC circuit breakers, preventing $2M in annual outages.
- Power Generation: Controls GE’s 7FA gas turbines with IEC 61850 compliance, ensuring grid stability during load shifts.
- Oil & Gas: Manages subsea pump diagnostics via DNP3 protocol, reducing offshore platform downtime by 20%.
- Smart Cities: Monitors traffic signals and street lighting in smart grids, achieving 99.9% uptime in urban infrastructure projects.
Example: A German railway network improved signaling reliability by 35% using D20-EME 10BASE-T to connect legacy RS-485 switches to modern Ethernet systems.
- Dual Voltage Flexibility: Supports both AC and DC inputs (110–240 VAC/110–370 VDC) vs. single-voltage modules in comparable products, reducing inventory SKUs by 50%.
- Faster Serial Communication: 7× RS-232/485 ports with 9600–115.2 kbps speeds vs. 4 ports in 竞品，enabling multi-device integration.
- Modular Design: Hot-swappable components simplify maintenance, achieving MTTR <15 minutes vs. 30 minutes industry average.
D20-EME
- Legacy System Integration: Choose D20-EME 10BASE-T for retrofitting D.20 protocol devices into modern PACSystems RX3i platforms.
- High-Temperature Sites: Opt for the -EME variant (wide temp) for applications in steel mills or desert solar farms.
- Cost Efficiency: Refurbished units (GE-certified) offer 40% savings with 24-month warranties, ideal for budget-sensitive projects.
- Wiring: Use 18 AWG cables for Ethernet connections; torque terminals to 4.0 N·m.
- Safety: Power off for 15 minutes before installation; use insulated tools for live voltage checks.
- Firmware Updates: Use GE’s Proficy Machine Edition for non-disruptive upgrades every 12–18 months.
