EMERSON 5X00226G01

1. Product Description

2. Product Parameters

Parameter	Specification
Interface Type	6 × 10/100 Mbps Fast Ethernet (RJ45) + 2 × 10/100 Mbps redundant uplink ports
Communication Protocols	Modbus TCP/RTU, PROFINET, EtherNet/IP, SNMP, DHCP, IPv4/IPv6
Power Supply	24 VDC (±10%), 15 W power consumption
Operating Temperature	-40°C to 85°C (extended range)
Dimensions	120 mm (W) × 100 mm (H) × 80 mm (D)
Weight	1.5 kg
Certifications	CE, RoHS, IEC 61000-4-2 (ESD protection), IEC 61000-4-4 (EFT protection)
Redundancy Support	Dual Ethernet uplink ports for network redundancy
Data Transfer Rate	Up to 100 Mbps per port

5X00226G01

3. Advantages and Features

1. Extended Environmental Performance:
   • The 5X00226G01 operates reliably in extreme temperatures (-40°C to 85°C), making it suitable for outdoor installations, high-temperature industrial zones, or cold-climate applications.
2. Multi-Protocol Compatibility:
   • Native support for major industrial protocols reduces the need for additional gateways, simplifying integration with both legacy and modern systems. For example, in a chemical plant, this feature allowed seamless connection of 50+ field devices from different manufacturers, reducing setup time by 30%.
3. Redundant Network Architecture:
   • Dual uplink ports enable automatic failover in case of network faults, ensuring 99.99% uptime critical for power plants or offshore platforms.
4. Advanced Diagnostics:
   • Real-time LED indicators for power, link status, and error conditions enable quick troubleshooting, while built-in self-tests detect sensor or cable faults, minimizing maintenance delays.

4. Application Areas and Use Cases

• Power Generation: Used in thermal, nuclear, and renewable energy plants to monitor turbines, generators, and substations, ensuring stable power output through real-time data integration with the Ovation DCS.
• Oil & Gas: Deployed in offshore platforms and refineries to connect distributed control systems with pumps, compressors, and safety valves, enabling precise process control and emergency shutdown capabilities.
• Manufacturing: Integrates CNC machines, robotics, and quality control systems in smart factories, facilitating real-time production data analysis and optimization.

5. Competitor Comparison

• Wider Temperature Range: Operates at -40°C to 85°C, 15°C higher than most competing models, making it a preferred choice for extreme environments.
• Higher Port Density: Offers 6 local Ethernet ports, supporting more simultaneous device connections than many alternatives, which typically provide 4 or fewer ports.
• Integrated Redundancy: Built-in dual uplink ports eliminate the need for external redundancy modules, reducing hardware costs and complexity.


  5X00226G01

6. Selection Recommendations

1. System Compatibility:
   • Ensure compatibility with your existing control system (e.g., Emerson Ovation or third-party PLC/DCS) by verifying protocol support and network architecture requirements.
2. Environmental Needs:
   • Choose the 5X00226G01 for applications requiring operation in extreme temperatures (-40°C to 85°C), such as steel mills or arctic oil fields.
3. Scalability:
   • Opt for this module if your application requires connecting 50+ field devices, as its 6 local ports and high data transfer rate efficiently handle large-scale deployments.
4. Budget Considerations:
   • While the module offers premium features like redundancy and wide temperature tolerance, evaluate if these capabilities align with your project’s reliability and performance needs.

7. Precautions

1. Installation:
   • Use shielded Ethernet cables and proper grounding to minimize EMI interference, especially in environments with high-power machinery.
   • Follow Emerson’s installation guidelines to ensure correct wiring of power and network connections, avoiding reverse polarity or voltage surges.
2. Operation:
   • Do not exceed the rated input voltage (24 VDC ±10%) to prevent hardware damage.
   • Monitor front-panel LEDs regularly to identify early signs of network instability or power issues.
3. Maintenance:
   • Clean dust and debris from the module’s vents quarterly to maintain optimal thermal performance.
   • Update firmware using Emerson’s official tools to access the latest security patches and protocol enhancements, ensuring long-term compatibility and reliability.
