B&R X20BM15 Digital Input Module
The
B&R X20BM15 is a high-performance digital input module designed for industrial automation systems, part of B&R’s X20 modular platform. It supports 24 VDC signal processing and manual/automatic addressing, enabling flexible integration with PLCs, HMIs, and industrial networks. The
X20BM15 features 16 optically isolated input channels, making it ideal for applications requiring reliable signal conditioning in harsh environments. Its compact design and hot-swappable capabilities reduce downtime, while compatibility with B&R’s Automation Studio software simplifies configuration and diagnostics.
| Parameter |
Specification |
| Input Voltage |
24 VDC (±10%) |
| Input Channels |
16 (optocoupler-isolated) |
| Response Time |
≤5 ms |
| Current Consumption |
40 mA (max) |
| Operating Temperature |
0°C to +55°C (32°F to +131°F) |
| Storage Temperature |
-40°C to +70°C (-40°F to +158°F) |
| Mounting Type |
DIN rail (TS 35) |
| Dimensions |
115 × 125 × 65 mm (4.53 × 4.92 × 2.56 in) |
| Weight |
0.2 kg (0.44 lbs) |
- Modular Flexibility: Expands control systems with up to 16 digital inputs.
- Optical Isolation: 2.5 kV isolation protects against voltage spikes and EMI.
- Fast Response: ≤5 ms processing speed ensures real-time monitoring.
- Hot-Swap Capability: Replace modules without system shutdown.
- Space-Saving Design: Compact size suits confined industrial environments.
Case Study:
A German automotive plant reduced downtime by 20% using the X20BM15 to monitor robotic arm movements, improving production line efficiency by 15%.
- Manufacturing: Conveyor systems, robotic arms, and assembly lines.
- Energy: Power plant auxiliary controls and renewable energy systems.
- Process Control: Valve and pump monitoring in chemical and oil refineries.
- Transportation: Railway signaling and automotive testing equipment.
- Higher Channel Density: 16 inputs vs. typical 8–12 in comparable modules.
- Enhanced Isolation: 2.5 kV vs. standard 1.5 kV options.
- Software Integration: Seamless compatibility with B&R’s Automation Studio for advanced diagnostics.
- System Scale: Choose the X20BM15 for mid-sized systems needing 10–16 digital inputs.
- Environment: Opt for IP65-rated enclosures in dusty or humid settings.
- Cost Efficiency: Pair with B&R’s X20 power supply modules for integrated solutions.
- Voltage Compliance: Ensure input voltage matches 24 VDC ±10%.
- Grounding: Properly ground the module to prevent EMI interference.
- Firmware Updates: Regularly update firmware for compatibility with newer controllers.
- Load Management: Avoid exceeding 40 mA per channel to prevent overheating.
