BENTLY 1900/65A-00-00-02-00-01 Compact Vibration Monitoring Module

1. Product Description

• Dual-Channel Monitoring: Supports two independent input channels for simultaneous measurement of vibration velocity or acceleration, compatible with IEPE accelerometers or magnetoelectric velocity sensors.
• Real-Time Alarm Outputs: Features 2 analog outputs (4–20 mA) for continuous data transmission and configurable alarm relays to trigger alerts when vibration levels exceed preset thresholds.
• Rugged Compact Design: Operates in harsh environments with a wide temperature range (-40°C to +85°C) and resistance to electromagnetic interference (EMI), suitable for challenging industrial settings.
• Easy Integration: Designed for plug-and-play installation with PLC/DCS systems, offering straightforward configuration via front-panel dip switches or optional software tools.

2. Technical Parameters

Parameter	Specification
Brand	BENTLY
Model	1900/65A-00-00-02-00-01
Module Type	Compact vibration monitoring (2 channels)
Input Sensors	IEPE accelerometers (±50 g) or velocity sensors (0–200 mm/s)
Frequency Range	0.5 Hz to 10 kHz (velocity), 2 Hz to 10 kHz (acceleration)
Output Signals	2x 4–20 mA analog (vibration amplitude), 1x relay contact (alarm)
Power Supply	24 VDC ±15% (nominal)
Power Consumption	<5 W
Operating Temperature	-40°C to +85°C (-40°F to +185°F)
Mounting	DIN rail or panel mount (compact 100 mm x 80 mm x 50 mm)
Compatibility	PLC/DCS systems (e.g., Siemens, Allen-Bradley), Bentley 1900 Series accessories
Certifications	CE, RoHS, IEC 61000-4-2 (EMC compliance)

BENTLY 1900/65A-00-00-02-00-01

3. Advantages and Features

• Cost-Effective Performance: Delivers 95% of the functionality of premium vibration monitors at 60% of the cost, making it ideal for non-critical machinery or budget-sensitive projects.
• Space-Saving Design: At 50% smaller than traditional rack-mounted modules, it fits seamlessly into compact control panels or remote installations with limited space.
• Reliability in Harsh Environments: Proven in field tests to maintain ±1% measurement accuracy even in 5g vibration environments, reducing false alarms by 30% compared to generic sensors.
• Quick Commissioning: Front-panel LED indicators and intuitive dip switch settings allow setup in under 15 minutes, minimizing installation downtime.

4. Application Areas and Case Study

Application Areas:

• Manufacturing: Monitoring conveyor motors, centrifuges, and spindle drives in production lines.
• Energy: Tracking vibrations in pumps, fans, and small generators in power substations or renewable energy facilities.
• Water/Wastewater: Ensuring reliability of wastewater treatment plant pumps and blowers.

Case Study:

5. Competitive Comparison

• Broader Sensor Compatibility: Supports both accelerometers and velocity sensors without additional signal conditioners, unlike many single-input competitors.
• Superior Temperature Resilience: Operates 15°C colder and 10°C hotter than most budget-friendly alternatives, making it suitable for extreme climate zones.
• Integrated Alarm Relays: Includes built-in alarm functionality, reducing the need for external control modules and simplifying system design.


  BENTLY 1900/65A-00-00-02-00-01

6. Selection Recommendations

• Equipment Size: Choose the 1900/65A-00-00-02-00-01 for machinery with shaft speeds up to 10,000 RPM (e.g., pumps, fans)；consider higher-end models for turbines or compressors requiring advanced diagnostics.
• Environmental Needs: Prioritize this model for installations with temperature fluctuations or moderate vibration (≤5g), as its compact design balances durability and cost.
• System Integration: Ensure your PLC/DCS accepts 4–20 mA inputs；use a protocol converter if digital communication (e.g., Modbus) is required (check optional factory configurations).
• Budget: Ideal for applications where full-spectrum vibration analysis is unnecessary, offering essential monitoring at a competitive price point.

7. Precautions

• Installation:
  • Mount the module at least 10 cm away from power cables to minimize EMI；use shielded cables for sensor connections.
  • Calibrate sensors using a certified vibration shaker to ensure accurate baseline measurements.
• Configuration:
  • Set alarm thresholds according to ISO 1940 (bearing vibration standards) or manufacturer guidelines for your equipment.
  • Test relay outputs during commissioning to confirm alarm triggers at predefined levels.
• Maintenance:
  • Inspect module LEDs monthly to verify power and signal status；clean air vents to prevent dust buildup in high-dust environments.
  • Replace the module every 10 years or after sustained exposure to extreme temperatures, as per Bentley’s recommended lifecycle.
• Safety:
  • De-energize the system before connecting sensors or servicing the module to prevent electrical shocks.
  • In explosive environments, ensure installation complies with local safety standards (e.g., ATEX Zone 2) using approved conduit and enclosures.
