Description
ZYGO 8070-0279-01 is a critical component designed for advanced metrology and precision control systems, particularly in high-performance laser interferometers and nano-positioning applications. This model serves as a key interface module, enabling seamless integration between optical sensors and control systems to achieve sub-nanometer accuracy in industrial and research environments.
The
ZYGO 8070-0279-01 is engineered to support multi-axis motion control and real-time data acquisition in complex metrology setups. It acts as a bridge between ZYGO’s laser interferometers (e.g., ZMI series) and external systems, providing high-speed signal processing and synchronization capabilities. With its compact form factor and rugged design, this module is ideal for demanding applications where stability and precision are paramount. Key features include:
- Multi-Protocol Compatibility: Supports EtherCAT, TCP/IP, and USB interfaces for flexible integration with PLCs, PCs, and automation networks.
- High-Speed Data Processing: Enables real-time feedback control with a bandwidth of up to 20 kHz, ensuring rapid response to dynamic positioning commands.
- Adaptive Noise Cancellation: Built-in filters reduce electromagnetic interference (EMI), enhancing reliability in high-noise industrial settings.
- Calibration Integration: Automatically loads calibration data from connected sensors, ensuring consistent accuracy across different measurement setups.
| Parameter |
Specification |
| Input Voltage |
100–240V AC, 50/60Hz |
| Output Voltage Range |
±10V (analog) for actuator control |
| Communication Interfaces |
EtherCAT (Gbit), TCP/IP, USB 2.0 |
| Bandwidth |
20kHz (closed-loop) |
| Positioning Resolution |
<0.1nm (with compatible interferometers) |
| Linearity |
±0.05% of full scale |
| Operating Temperature |
0°C to 40°C (non-condensing) |
| Dimensions |
170mm x 150mm x 50mm (W x H x D) |
| Mounting |
Rack-mountable or desktop placement |
8070-0279-01
- Ultra-Precision Control: The 8070-0279-01 achieves sub-nanometer resolution, making it suitable for applications such as EUV lithography and semiconductor manufacturing, where atomic-level precision is critical.
- Modular Design: Its plug-and-play architecture simplifies system expansion, allowing users to add up to 16 axes of control in a single network.
- Real-Time Diagnostics: Integrated sensors monitor temperature, voltage, and signal integrity, providing instant alerts for maintenance and fault correction.
- Energy Efficiency: Low-power standby mode reduces energy consumption by 30% compared to legacy controllers, ideal for 24/7 operation.
- Software Integration: Compatible with ZYGO’s MX software suite, enabling advanced data analysis, visualization, and automated measurement sequences.
The ZYGO 8070-0279-01 is widely used in:
- Semiconductor Manufacturing: Controlling wafer stages in lithography tools to achieve nanometer-scale pattern alignment.
- Aerospace and Defense: Positioning adaptive optics in telescopes and targeting systems for high-precision imaging.
- Research Laboratories: Driving nano-positioning stages in scanning probe microscopy and interferometry experiments.
Case Study:
A leading semiconductor manufacturer deployed the 8070-0279-01 to enhance the accuracy of their EUV lithography tool. By integrating the module with ZYGO’s ZMI 7714 laser interferometer, they achieved a 40% reduction in positioning errors, improving chip yield by 15% and reducing downtime from alignment issues by 25%.
Compared to similar modules in the market, the ZYGO 8070-0279-01 offers:
- Higher Bandwidth: 20kHz closed-loop bandwidth vs. typical 10kHz found in competing systems, enabling faster response to dynamic motion commands.
- Wider Voltage Output: ±10V analog output supports a broader range of piezoelectric actuators.
- Integrated Diagnostics: Real-time health monitoring reduces troubleshooting time by 50% compared to controllers without built-in analytics.
8070-0279-01
When selecting the ZYGO 8070-0279-01, consider:
- System Compatibility: Ensure your control system supports EtherCAT or USB interfaces for seamless integration.
- Precision Requirements: Verify the module’s resolution (<0.1nm) aligns with your application’s accuracy needs.
- Environmental Conditions: Confirm the operating temperature (0°C to 40°C) and humidity levels match your setup.
- Software Ecosystem: Leverage ZYGO’s MX software for advanced data processing and automation.
- Installation:
- Mount the module in a well-ventilated area to prevent overheating.
- Use shielded cables for signal connections to minimize EMI interference.
- Operation:
- Do not exceed the rated output voltage or current to avoid damage to connected actuators.
- Calibrate the system using ZYGO’s alignment tools before initial use.
- Maintenance:
- Regularly update firmware via ZYGO’s Control Suite to access the latest features.
- Inspect cooling vents quarterly and clean with compressed air to maintain thermal efficiency.
