ABB XVC768102 3BHB007211R102 Current Measurement Scale Module

1. Product Description

• High Accuracy: Ensures ±0.5% measurement precision across a wide range of current values, minimizing errors in critical applications.
• Wide Current Range: Supports up to 7 MVA (megavolt-amperes) capacity, making it suitable for large industrial motors and generators.
• Rugged Construction: Built to withstand extreme temperatures (-20°C to +60°C) and electromagnetic interference (EMI), ensuring reliable operation in harsh environments.
• User-Friendly Design: Simplifies installation and configuration with plug-and-play connectivity and intuitive diagnostics.
• Compatibility: Specifically designed for ABB’s ACS6000 drive systems, ensuring seamless integration with existing hardware and software ecosystems.

2. Technical Parameters

Parameter	Specification
Brand	ABB
Model	XVC768102 3BHB007211R102
Type	Current Measurement Scale Module
Voltage Supply	24V DC ±10%
Current Range	0–7 MVA (AC)
Measurement Accuracy	±0.5%
Communication Interface	Digital input/output (via drive system)
Operating Temperature	-20°C to +60°C (non-condensing)
Storage Temperature	-40°C to +85°C
Dimensions (W×H×D)	160mm × 160mm × 120mm
Weight	0.8 kg
Certifications	CE, RoHS, IEC 61131-2 compliant
Compatibility	ABB ACS6000 medium-voltage AC drives

XVC768102 3BHB007211R102

3. Advantages and Features

• Precision Measurement: The XVC768102 3BHB007211R102 reduces current measurement errors by up to 25% compared to standard analog sensors, ensuring accurate system feedback for optimal performance 1.
• Wide Environmental Resilience: Operates effectively in extreme temperatures and high-EMI environments, outperforming many competitors limited to narrower ranges.
• Cost-Effective Integration: Eliminates the need for external current transformers, reducing hardware costs by up to 20% and simplifying system design.
• Advanced Diagnostics: Built-in self-test functionality and error reporting enable proactive maintenance, minimizing unplanned downtime.

4. Application Areas and Case Study

Application Areas:

• Power Generation: Monitors generator output and grid synchronization in power plants.
• Industrial Drives: Integrates with ACS6000 drives to control large motors in manufacturing, mining, and water treatment facilities.
• Renewable Energy: Supports current regulation in wind turbines and solar inverters.

Case Study:

5. Competitive Positioning

• Higher Accuracy: Maintains ±0.5% precision, while many competitors offer ±1% or lower.
• Dedicated Compatibility: Optimized for ABB’s ACS6000 drives, eliminating compatibility issues with third-party components.
• Integrated Diagnostics: Provides built-in fault detection, unlike some competitors requiring external monitoring tools.


  XVC768102 3BHB007211R102

6. Selection Recommendations

• System Compatibility: Verify that your drive system is ABB ACS6000 or a compatible variant to ensure seamless integration.
• Current Requirements: Ensure the module’s 7 MVA capacity matches your application’s peak current demands.
• Environmental Assessment: Prioritize this module for high-temperature or high-EMI environments.
• Technical Support: Partner with suppliers offering ABB-certified technical assistance for installation and troubleshooting.

7. Precautions

• Installation Best Practices:
  • Power down the drive system before installing the module to prevent electrostatic discharge (ESD) damage.
  • Use shielded cables for signal connections to minimize EMI interference.
• Maintenance and Calibration:
  • Calibrate the module annually using ABB’s official tools to ensure accuracy.
  • Update firmware regularly to access new features and security patches.
• Storage and Handling:
  • Store unused modules in dry, dust-free environments within the specified temperature range.
  • Handle with anti-static equipment to protect sensitive components.
