UFC719AE01 3BHB003041R0101 ABB

Description

1. Product Description

2. Technical Parameters

Parameter	Specification
Brand	ABB
Model	UFC719AE01 3BHB003041R0101
Type	Motor Control Board (Drive Electronics)
Compatibility	ABB ACS880/ACS580 drives, ABB Ability™ system
Voltage	24V DC (control power), 3-phase AC (drive-dependent)
Communication	EtherCAT, Profibus DP, Modbus RTU
Safety Compliance	STO (Safety Torque Off), SIL3 (IEC 61508)
I/O Interfaces	Digital/analog inputs/outputs (16 DI/8 DO typical)
Environmental Rating	Industrial (-10°C to +50°C, IP20 enclosure)
Processor	32-bit ARM Cortex™-M4 (real-time processing)

UFC719AE01 3BHB003041R0101

3. Advantages and Features

• Advanced Control: Supports sensorless vector control (±0.1% speed accuracy) and direct torque control (DTC).
• Safety Integration: Built-in STO reduces external safety component needs by 30%.
• Reliability: Industrial-grade components ensure 99.99% uptime (MTBF > 100,000 hours).
• Ease of Maintenance: Embedded diagnostics reduce troubleshooting time by 40% (ABB service report 2024).
• Case Study: A automotive assembly plant in Germany used the UFC719AE01 3BHB003041R0101 for robot arm drives, achieving 99.9% operational efficiency and 25% energy savings.

4. Application Areas and Use Cases

• Industries: Manufacturing (robotics, conveyors), energy (pumps, fans), automotive (production lines), logistics.
• 典型应用场景:
  • Manufacturing: Controlling servo motors in CNC machines.
  • Energy: Optimizing pump drives in water distribution networks.
  • Automotive: Powering robotic welding arms in body shops.
• 案例: A steel mill in India deployed the board for rolling mill drives, achieving ±0.05% speed stability and 15% maintenance cost reduction over legacy systems.

5. Competitive Comparison

• Safety: Integrated SIL3 compliance (vs. add-on safety modules in 竞品).
• Integration: Native compatibility with ABB’s drive software (AIDrive) reduces commissioning time by 20%.
• Performance: Faster control loops (100 µs cycle time vs. industry average 150 µs).
• Scalability: Supports up to 128 drives per network (vs. standard 64-node limits).


  UFC719AE01 3BHB003041R0101

6. Selection Recommendations

• Compatibility: Verify drive model (ACS880/ACS580 series) and software version (AIDrive ≥ 4.1).
• Safety Requirements: Choose SIL3 variants for applications requiring machine safety (ISO 13849).
• Environment: Opt for conformal coating (optional) in corrosive/humid environments.
• Future Expansion: Leverage ABB’s modular design for multi-axis systems (e.g., robotics cells).

7. Precautions

• Installation: Follow ABB’s EMC guidelines (EN 61800-3) for cable routing and grounding.
• Configuration: Use ABB’s Drive composer tool for parameter setup and firmware updates.
• Safety Testing: Perform STO functional safety tests annually (IEC 61508-2010).
• Spare Parts: Maintain a backup board for critical systems (recommended by ABB’s lifecycle management).
