Description
The
ABB TU810V1 3BSE013230R1 is a compact module termination unit (MTU) designed for ABB’s S800 I/O system, a distributed process I/O solution for industrial automation. As part of ABB’s modular architecture, the
TU810V1 3BSE013230R1 provides secure termination for signal cables, enabling seamless integration with digital/analog modules (e.g., DI810, AO810V2) in the S800 series. With 2×8 signal terminals and 50V isolation, this MTU supports field-level connectivity for sensors, actuators, and control devices in harsh environments. Its compact design (30×20×20 cm) and DIN-rail mounting simplify installation, while hot-swap capability allows module replacement without system downtime. The
TU810V1 3BSE013230R1 is ideal for applications requiring reliable signal routing in industries such as manufacturing, energy, and water treatment.
| Parameter |
Specification |
| Model |
TU810V1 3BSE013230R1 |
| Brand |
ABB |
| Type |
Compact Module Termination Unit (MTU) |
| Terminals |
2×8 signal terminals |
| Voltage Isolation |
50V |
| Compatibility |
ABB S800 I/O modules (DI810, DO810, AI810, etc.) |
| Mounting |
DIN rail (horizontal/vertical) |
| Dimensions |
30 mm (W) × 20 mm (H) × 20 mm (D) |
| Weight |
~0.2 kg |
| Environment |
-25°C to +60°C, compliant with G3 severity |
| RoHS Compliance |
Yes (EU Directive 2011/65/EU) |
TU810V1 3BSE013230R1
- Modular Design: Enables quick integration with S800 I/O modules, reducing cabling complexity.
- Hot-Swap Capability: Modules can be replaced during operation, minimizing downtime.
- Space-Saving: Compact size (30×20×20 cm) saves panel space in crowded installations.
- Reliable Isolation: 50V isolation protects against signal interference in noisy environments.
- Wide Temperature Range: Operates from -25°C to +60°C, suitable for harsh industrial settings.
- Easy Installation: DIN-rail mounting and standardized terminals simplify setup.
Case Study: A power plant reduced wiring costs by 30% using the TU810V1 3BSE013230R1 with AI810 analog modules, streamlining sensor connections in boiler control systems.
- Industries: Manufacturing, oil/gas, power generation, water/wastewater treatment.
- Scenarios: Termination for I/O modules in distributed control systems (DCS), PLCs, and field devices.
- Use Case: A chemical plant used the TU810V1 3BSE013230R1 to terminate 16-channel digital outputs (DO810) for valve actuators, ensuring reliable signal transmission in a corrosive environment.
Compared to generic termination units:
- Superior Compatibility: Exclusive support for ABB’s S800 I/O ecosystem, ensuring plug-and-play integration.
- Higher Density: 16 terminals in a compact form factor vs. 8–12 terminals in standard MTUs.
- Enhanced Safety: G3-compliant construction for corrosive environments (vs. basic IP20-rated alternatives).
- Hot-Swap Support: Unique to ABB’s S800 series, enabling maintenance without system shutdown.
TU810V1 3BSE013230R1
- System Compatibility: Ensure use with ABB S800 I/O modules (e.g., DI810, AO810V2).
- Terminal Requirements: Choose 16-terminal configuration for medium-scale I/O needs; scale with TU847 (for Profibus modules) for advanced systems.
- Environment: Opt for G3-compliant MTUs (like TU810V1) for corrosive or dusty sites.
- Cost Efficiency: Balances performance (hot-swap, isolation) with budget-friendly pricing vs. premium-brand alternatives.
- Installation: Follow ABB’s wiring guidelines (shielded cables for analog signals; torque terminals to 0.5 N·m).
- Safety: Disconnect power before module replacement; avoid contact with live terminals.
- Maintenance: Inspect terminals for corrosion or 松动 (loose connections) quarterly.
- Temperature: Ensure ambient temperature ≤60°C; avoid direct sunlight or moisture.
声明: Shanxi Xinyeda International Trade Co., Ltd. is your trusted partner for
TU810V1 3BSE013230R1 and ABB S800 I/O solutions. We provide genuine spare parts, technical support, and customized automation services. Visit
www.xydcontrol.com or contact us to optimize your industrial control system.
