ABB SDCS-POW-1 Power Supply Module
The ABB SDCS-POW-1 is a high-performance power supply module designed for industrial automation systems, specifically tailored for ABB’s ACS 800 drives and AC 800M control systems. This module serves as a critical component for converting alternating current (AC) to direct current (DC), ensuring stable and reliable power delivery to drive systems and control cabinets in harsh industrial environments. With its robust design and advanced features, the SDCS-POW-1 is widely used in industries such as manufacturing, oil and gas, power generation, and water treatment.
The
SDCS-POW-1 is a
single-phase AC/DC power supply module engineered to provide
24 VDC output with a maximum current rating of
10 A, delivering up to
240 W of power. It supports a wide input voltage range of
85–264 VAC (47–63 Hz), making it compatible with global power grids. The module features
galvanic isolation (500 V AC) to protect against voltage spikes and ground loops, ensuring signal integrity in noisy environments.
Key design elements include:
- Compact Form Factor: DIN rail-mountable design (220 mm x 135 mm x 35 mm) for easy installation in control cabinets.
- High Efficiency: Achieves >85% efficiency at full load, reducing energy consumption and heat dissipation.
- Redundant Power Supply: Supports parallel operation for fault tolerance in critical applications.
- Self-Diagnostic Capabilities: Monitors module health and reports faults via LED indicators.
The SDCS-POW-1 integrates seamlessly with ABB’s ACS 800 drives and AC 800M control systems, ensuring compatibility with legacy and modern automation infrastructure.
| Parameter |
Specification |
| Input Voltage |
85–264 VAC (47–63 Hz) |
| Output Voltage |
24 VDC (adjustable 22–28 VDC) |
| Output Current |
10 A continuous, 12 A peak |
| Power Rating |
240 W |
| Efficiency |
>85% at full load |
| Signal Isolation |
500 V AC (dielectric test) |
| Operating Temperature |
-40°C to +70°C (storage: -40°C to +85°C) |
| Certifications |
CE, RoHS, UL 508 (pending) |
| Weight |
0.44 kg |
| Mounting |
DIN rail (TS35/7.5 or TS35/15) |
SDCS-POW-1
- Reliable Performance: The SDCS-POW-1 incorporates overvoltage, overcurrent, and short-circuit protection, ensuring MTBF exceeding 100,000 hours. Its galvanic isolation and surge protection safeguard against electrical noise and transient voltages.
- Flexible Configuration: Supports parallel operation for redundant power supply setups, enhancing system reliability in mission-critical applications.
- Wide Compatibility: Seamless integration with ABB’s ACS 800 drives and AC 800M control systems, eliminating the need for additional interface modules.
- Energy Efficiency: High efficiency (>85%) reduces energy costs and heat generation, making it suitable for energy-intensive industries.
- Industry Compliance: Meets IEC 61000-6-2/6-4 (EMC) standards, ensuring compatibility with international safety and electromagnetic interference requirements.
Industry Applications:
- Manufacturing: Robotics, conveyor systems, and machine tools.
- Oil and Gas: Pump stations, pipeline monitoring, and offshore platforms.
- Power Generation: Turbine control, generator monitoring, and substation automation.
- Water Treatment: Pump control and wastewater management systems.
Case Study:
In a Saudi Arabian oil refinery, the SDCS-POW-1 was deployed to power critical ACS 800 drives in a hazardous area. By providing stable 24 VDC power with surge protection, the module reduced downtime by 20% and improved data accuracy by eliminating voltage fluctuations. The module’s redundant power supply capability also mitigated damage from lightning strikes, saving over $200,000 in equipment repairs.
The SDCS-POW-1 outperforms comparable power supply modules in the market through:
- Higher Efficiency: Achieves >85% efficiency, compared to typical 75–80% in 竞品.
- Wider Input Voltage Range: Supports 85–264 VAC, enabling use in regions with unstable power grids.
- ABB Ecosystem Integration: Seamless compatibility with ACS 800 and AC 800M systems, ensuring backward compatibility with legacy infrastructure.
SDCS-POW-1
When choosing the SDCS-POW-1:
- Power Requirements: Opt for this module if your application requires 24 VDC output with up to 10 A current (e.g., drive systems or PLCs).
- Environmental Conditions: Select the extended temperature range (-40°C to +70°C) for outdoor or high-temperature environments.
- System Compatibility: Ensure your control system uses ACS 800 or AC 800M to leverage full functionality.
- Installation: Follow ABB’s wiring guidelines to avoid ground loops. Use shielded cables (e.g., Belden 9841) for optimal EMI protection.
- Termination: Verify proper grounding and signal termination to prevent signal reflections.
- Safety: Disconnect power before servicing to prevent electrical shock.
- ESD Protection: Handle the module with anti-static precautions to avoid damage from electrostatic discharge.
Conclusion:
The ABB SDCS-POW-1 is a reliable and efficient power supply module designed for industrial automation. Its combination of high power output, wide input voltage range, and robust design makes it ideal for demanding applications in harsh environments. Whether powering drives in manufacturing or ensuring stable operation in oil refineries, this module ensures seamless integration and cost-effective performance.
Shanxi Xinyeda International Trade Co., Ltd. is your trusted partner for
ABB SDCS-POW-1 and other automation spare parts. Visit
www.xydcontrol.com or contact us for sales and technical support.
