SDCS-PIN48-SD

Description

ABB SDSC-PIN48-SD is a high-performance pulse transformer board that is widely used in industrial automation and power electronics. Here is a detailed description of the product:

ABB SDSC-PIN48-SD Product description

ABB SDSC-PIN48-SD is a pulse transformer board designed for signal isolation, voltage conversion and system reliability. It uses pulse width modulation (PWM) technology to achieve accurate conversion and transmission of electrical energy, thereby improving energy efficiency and reducing waste. The product is part of the ABB Ability™System 800xA® family and features high integration, modular design and reliability.

Product parameter

Electrical parameters:

Input voltage: 220VAC.

Output voltage range: 0-480VAC.

Rated power: 48kW.

Rated current: Maximum 10A.

Operating temperature range: -20°C to +55°C.

Storage temperature range: -25°C to +70°C.

Physical parameters:

Size: 500mm x 300mm x 200mm.

Weight: About 20kg.

Protection grade: IP20, suitable for general industrial environment.

Other features:

Supports PWM control mode.

With isolation protection function.

High reliability and compact design.

Product specification

Input voltage: 220VAC.

Output voltage: 0-480VAC.

Rated power: 48kW.

Size: 500mm x 300mm x 200mm.

Weight: About 20kg.

Protection level: IP20.

series

The ABB SDSC-PIN48-SD is part of the ABB Ability™System 800xA® series, which features high integration, modular design and reliability and is widely used in industrial automation systems.

trait

High performance: The use of advanced electronic components and materials to achieve high-speed, high-precision pulse signal transmission and control.

High reliability: suitable for stable operation under complex environmental conditions.

Easy integration: Provides standard interfaces and protocols for easy integration with other devices or systems.

Compact design: moderate size for easy installation and integration.

Function and use

The main role of ABB SDSC-PIN48-SD is as a signal isolation and conversion module for drive control and inverter control in industrial automation systems. Its functions include:

Signal isolation: Ensure the safety and reliability of signal transmission.

Voltage conversion: The input voltage is converted to the output voltage suitable for the device.

Improve system stability: The isolation protection function improves the overall system reliability.

Application field

ABB SDSC-PIN48-SD is widely used in the following areas:

Mechanical construction: For precise control of motor speed or position.

Metallurgy: Supports stable operation of high power equipment.

Mining: Adapting to the needs of industrial automation in harsh environmental conditions.

Textile, printing, chemical, food and other industries: to meet the needs of different industries for power and signal transmission.
