Description

The ABB REM610 is a multi-functional motor protection relay designed for medium and large asynchronous low and high voltage motors and belongs to the ABB Relion®610 series. The following is a detailed description of ABB REM610 products:

 ABB REM610 Product description

ABB REM610 is an integrated motor protection device with a full range of protection features, including overheat protection, start-up supervision, operation stall protection, ground fault protection, phase loss protection and more. It uses microprocessor technology and supports a self-monitoring system, which can detect the operating status of the motor in real time and issue an alarm in case of failure. In addition, the device supports a variety of communication protocols (such as Modbus, IEC 61850, DNP3.0, etc.) for easy integration with automated systems.

Product parameter

Rated voltage: 220V-660V.

Rated current: 5A-2000A.

Operating frequency: 50Hz/60Hz.

Protection class: IP40.

Operating temperature range: -20℃ to +60℃.

Storage temperature range: -40℃ to +85℃.

Relative humidity: ≤95% (non-condensing).

Dimensions: 120mm x 120mm x 95mm.

Product specification

The REM610 is suitable for medium voltage (e.g. 500kW to 2 MW) and low voltage motor equipment.

Supports single-phase, two-phase, or three-phase overcurrent protection, as well as directional ground fault protection.

Modular design for quick installation and maintenance of plug-in units.

A variety of input and output configurations are available, including analog input, digital input and output signals.

series

ABB REM610 belongs to the Relion®610 series, which also includes REM615, REM620 and other models, and is mainly used for protection and monitoring of low – and medium-voltage and high-voltage motors.

trait

Comprehensive protection functions: including overheat protection, start-up supervision, operation stop protection, ground fault protection, phase loss protection, etc.

High precision measurement: Support real-time measurement of current, voltage, power and other parameters.

Communication capability: Support Modbus, IEC 61850, DNP3.0 and other communication protocols.

User-friendly interface: Equipped with LCD display, support Chinese menu operation.

Modular design: easy to expand and maintain.

effect

The main role of the ABB REM610 is to protect the motor from overload, short circuit, phase loss and other electrical faults, while monitoring the motor operating condition, extending the motor life and improving the safety of the system.

use

ABB REM610 is widely used in the following areas:

Industrial automation systems.

Pumps, blowers, grinding machines and other equipment.

Substations, power plants, petrochemical and metallurgical industries.

Power cable outlets and power transformers requiring thermal overload protection.

Application field

ABB REM610 is suitable for the following industries:

The manufacturing industry.

The energy industry.

Water treatment and chemical industry.

Construction and infrastructure projects.
