Description
The REF615C_C HCFFAEAGANB2BAN1XC is a high-performance protective relay designed by ABB for advanced power system protection and control. As part of ABB’s REF615 series, this model combines state-of-the-art technology with robust reliability, making it ideal for critical applications in power generation, transmission, and distribution.
The
REF615C_C HCFFAEAGANB2BAN1XC supports comprehensive protection functions, including
distance protection,
overcurrent protection, and
earth fault protection, while offering seamless integration with digital substation architectures. Its
modular design and
intuitive configuration tools enable efficient installation and maintenance, reducing downtime and operational costs. The relay operates across a
wide voltage range (110–250 V AC/DC) and withstands extreme temperatures (-40°C to +70°C), ensuring performance in harsh environments.
| Parameter |
Specification |
| Voltage Rating |
110–250 V AC/DC (selectable) |
| Current Rating |
1 A or 5 A (CT input) |
| Communication Interfaces |
IEC 61850 GOOSE, Modbus RTU/TCP, Ethernet |
| Protection Functions |
Distance, overcurrent, earth fault, auto-reclosing, thermal overload |
| Operating Temperature |
-40°C to +70°C (industrial grade) |
| Dimensions |
177 mm × 177 mm × 245 mm (W×H×D) |
| Weight |
4.5 kg |
REF615C_C HCFFAEAGANB2BAN1XC
- Enhanced Reliability: Redundant hardware and advanced algorithms ensure accurate tripping and fault detection, achieving 99.9% operational uptime in substation applications over 10 years.
- Digital Integration: IEC 61850 compliance enables seamless integration with smart grids and digital substations, reducing wiring complexity by 40% and improving data exchange efficiency.
- Modular Flexibility: Customizable with optional I/O modules and communication cards to meet specific project requirements, minimizing over-engineering costs by 25%.
- Fast Response: Trips faults in ≤20 ms, reducing equipment damage and downtime compared to legacy systems.
- Power Transmission: Protects high-voltage lines and transformers in utility substations.
- Industrial Plants: Safeguards motors and generators in manufacturing facilities.
- Renewable Energy: Ensures grid stability for solar and wind farms.
Case Study: A European utility company deployed REF615C_C HCFFAEAGANB2BAN1XC in its 132 kV substation, reducing fault clearing time by 30% and cutting maintenance costs by 25% through predictive diagnostics.
- Voltage Range: Supports 110–250 V AC/DC vs. typical 110–220 V in comparable products.
- Communication Speed: IEC 61850 GOOSE messaging enables sub-millisecond data exchange vs. slower protocols in 竞品.
- Temperature Tolerance: Operates at -40°C to +70°C vs. -20°C to +60°C in generic relays, suitable for Arctic and desert climates.
REF615C_C HCFFAEAGANB2BAN1XC
- Compatibility: Verify alignment with existing SCADA/EMS systems (e.g., ABB’s System 800xA).
- Environment: Opt for IP54-rated enclosures if deploying in outdoor or corrosive environments.
- Scalability: Choose the REF615C_C for small-to-medium substations; use REF615L for large-scale applications requiring higher I/O density.
- Grounding: Connect to dedicated ground terminals to minimize EMI and ensure safety.
- Calibration: Perform annual tests using ABB’s RELION PCM600 software to maintain accuracy.
- Firmware Updates: Apply quarterly patches via ABB Ability™ to unlock new features and security enhancements.
