REF615 HBFEAEAGNDA1ABA1XG

Description

The ABB REF615 HBFEAEAGNDA1ABA1XG is a high-performance protection and control relay that belongs to the ABB Relion® family for feeder protection, measurement, control and monitoring functions in medium voltage power systems. Here is a detailed description of the product:

ABB REF615 HBFEAEAGNDA1ABA1XG Product description

The ABB REF615 HBFEAEAGNDA1ABA1XG is a modular design of medium voltage electrical equipment for substations, distribution networks and industrial automation systems. It integrates protection, measurement, communication and control functions to provide comprehensive protection and diagnostic services for electric motors, generators, transformers and other equipment.

Product parameter

Rated voltage: 400V (other CT ratings are optional).

Input voltage: Support three-phase voltage measurement, support Modbus RTU, IEC 61850, DNP3.0 and other optional communication protocols.

Output voltage: 0-480VAC.

Current measurement range: Maximum 1000A.

Frequency range: 50/60Hz.

Operating temperature: -20°C to +70°C.

Protection level: IP40 (optional up to IP54).

Dimensions: 120mm x 80mm x 45mm.

Power supply: 24V DC or 48V DC.

Product specification

Protection function: over current protection, short circuit protection, ground fault protection, under voltage protection, over voltage protection, differential protection, direction protection, reclosing and so on.

Measuring function: current, voltage, power, electric energy, etc.

Control function: circuit breaker control, isolation switch control, load control.

Communication function: Support RS-232, RS-485 and Ethernet communication.

series

The ABB REF615 belongs to the Relion® family, which is known for its high reliability, flexibility and advanced nature, and is widely used in power system protection, automation and control.

trait

Integration: Protection, measurement, control, and monitoring functions are integrated in a single module.

Flexibility: Supports a variety of communication protocols and ADAPTS to different network environments.

High accuracy: Provides accurate measurement data for evaluating the performance of power systems.

Ease-of-use: User-friendly and supports local and remote configurations.

Compact design: draw-out design saves installation space.

Function and use

The main functions of ABB REF615 HBFEAEAGNDA1ABA1XG are:

Provide power system feeder protection to ensure safe system operation.

Real-time monitoring and recording of power parameters, support fault diagnosis and event recording.

Control the operation of electrical equipment, such as circuit breakers and disconnecting switches.

Supports distributed power generation systems, suitable for radial, ring or grid distribution networks.

Application field

ABB REF615 is mainly used in the following areas:

Utility substation: Used for feeder protection and monitoring.

Industrial power systems: Provide reliable protection and control in plants, infrastructure projects.

Smart grid and new energy generation systems: Support the protection and monitoring of distributed generation systems.

Rail transit and municipal facilities: suitable for power protection in urban infrastructure.
