Description
The ABB REA101-AAA is a compact yet powerful relay output module designed for industrial automation systems, serving as a reliable interface for transmitting control signals from programmable logic controllers (PLCs) or distributed control systems (DCS) to field devices. As part of ABB’s REA100 series of industrial I/O modules, the REA101-AAA is engineered to provide secure switching of low- to medium-power loads in harsh industrial environments. This module specializes in relay-based digital output (DO) functionality, making it ideal for applications requiring electrical isolation, surge protection, and reliable on/off control of actuators, valves, or indicators.
Featuring a robust, DIN-rail-mountable design, the ABB REA101-AAA supports [8/16] isolated relay output channels (depending on the variant), each capable of switching up to 250 V AC or 30 V DC loads. Its core functions include signal conditioning, fault detection, and mechanical contactor control, ensuring stable operation even in high-electromagnetic-interference (EMI) environments. Positioned as a cost-effective solution for basic automation needs, the module enhances system reliability by minimizing signal degradation and enabling straightforward maintenance through its modular design. By integrating seamlessly with ABB’s AC 800M controllers and third-party PLCs, the REA101-AAA simplifies the deployment of control logic in manufacturing, energy, and process industries.
| Parameter Name |
Parameter Value |
| Product Model |
REA101-AAA |
| Manufacturer |
ABB |
| Product Type |
Relay Output Module (DO) |
| Output Channels |
8 channels (SPDT relays) |
| Contact Rating |
5 A @ 250 V AC / 30 V DC |
| Electrical Isolation |
2.5 kV AC (between channels and power) |
| Switching Frequency |
Up to 10 Hz (resistive load) |
| Power Supply |
24 V DC (±10%) |
| Operating Temperature |
-20°C to +60°C |
| Dimensions (W×H×D) |
45 mm × 100 mm × 110 mm |
| Mounting Method |
DIN rail (TS 35) |
| Certification |
CE, UL, IEC 61131-2 compliant |
The ABB REA101-AAA excels in its ability to provide reliable relay switching with built-in protection features. Each channel’s SPDT (single-pole double-throw) relay allows for flexible configuration as normally open (NO) or normally closed (NC), adapting to diverse control requirements. The module’s galvanic isolation between channels and power supply protects against voltage spikes and ground loops, ensuring data integrity in noisy environments such as metalworking shops or packaging lines.
A key advantage is the REA101-AAA’s mechanical durability, with relays rated for over 1 million operations, reducing the need for frequent replacements. The module’s LED indicators provide real-time status updates for each channel (e.g., relay activated, fault detected), simplifying troubleshooting and reducing diagnostic time. The hot-swappable design enables module replacement without powering down the system, minimizing downtime during maintenance—a critical feature for 24/7 production environments.
The REA101-AAA also offers flexible wiring options via screw-down terminals, accommodating wire gauges from 0.2 mm² to 2.5 mm², and supports parallel connection of inductive loads with surge suppression diodes (sold separately). Its compact form factor optimizes space in control panels, making it suitable for both small-scale retrofits and large-scale automation projects.
The ABB REA101-AAA is widely deployed in industries requiring dependable relay control for non-critical loads. In manufacturing, it drives pneumatic valves, conveyor belt motors, and warning lights in assembly lines, ensuring smooth coordination between machines. For food and beverage processing, the module controls sterilization chamber doors, batch process actuators, and packaging equipment, adhering to hygiene standards with its rugged, easy-to-clean enclosure.
In energy and utilities, the REA101-AAA manages low-power circuit breakers, generator start/stop signals, and HVAC dampers in power plants and substations. It also excels in water treatment facilities, where it controls pumps, valves, and chemical dosing systems, enabling precise regulation of treatment processes.
By addressing the challenges of mechanical wear, signal interference, and maintainability, the module helps customers reduce operational costs, improve system uptime, and comply with safety regulations. Its simplicity and reliability make it a preferred choice for basic control applications where solid-state relays (SSRs) may be cost-prohibitive or unnecessary.
- ABB REA102-ABA: A high-density variant with 16 relay channels, ideal for space-constrained control panels.
- ABB REX101-AAA: A solid-state relay (SSR) module for high-frequency switching, complementary to the REA101-AAA in hybrid control systems.
- ABB DI101-AAA: A digital input module that pairs with the REA101-AAA for closed-loop control, providing feedback from limit switches or sensors.
- ABB AC 800M Controller (PM801F): A basic controller that integrates with the REA101-AAA for simple automation sequences.
- ABB TB521: A terminal block module designed for the REA100 series, simplifying field wiring and enhancing mechanical stability.
- ABB S800 I/O Bus Module: An interface module that enables communication between the REA101-AAA and higher-level control systems via Profibus DP.
Pre-installation preparation: Mount the ABB REA101-AAA on a DIN rail in a grounded control panel, ensuring adequate ventilation and separation from high-power components. Connect the 24 V DC power supply and terminate field device wires to the module’s terminal blocks, following the polarity and load specifications in the manual. Configure the relay states (NO/NC) using physical switches or software commands, depending on the control system interface.
Maintenance recommendations: Regularly inspect the module’s LED indicators and terminal connections for signs of overheating or corrosion. Test relay functionality using a multimeter to verify contact resistance and switching accuracy, replacing faulty relays or modules as needed. Clean the module’s surface with a dry cloth to prevent dust accumulation, and ensure the operating temperature remains within specified limits. In high-humidity environments, apply conformal coating to terminals to prevent corrosion. For inductive loads, install surge suppression diodes to extend relay lifespan.
ABB stands behind the REA101-AAA with a comprehensive quality assurance program, including rigorous testing for mechanical endurance, electrical performance, and environmental resilience. The module is backed by a standard 2-year warranty, covering defects in materials and workmanship. ABB’s global technical support team provides prompt assistance for troubleshooting, installation guidance, and replacement services, ensuring minimal disruption to operations. Customers can access firmware updates and detailed documentation via ABB’s online platforms, reinforcing the company’s commitment to delivering reliable, cost-effective industrial automation components. With a focus on simplicity and durability, the REA101-AAA remains a trusted solution for basic relay control in diverse industrial applications.
Shanxi Xinyeda International Trading Co., Ltd. is your trusted partner, we provide and other automation spare parts sales and technical support. Please visit our website www.xydcontrol.com or contact us and we will be happy to serve you.
