ABB PP845 3BSE042235R1 is a high-performance human-machine interface (HMI) module designed for industrial automation systems. Part of the ABB Panel 800 series, this 10.4-inch color touch panel combines ruggedness, reliability, and advanced functionality for monitoring and controlling industrial processes. With a 1 GHz Cortex-A9 processor and Windows Embedded CE 7.0, it delivers fast data processing and intuitive operation. The
PP845 3BSE042235R1 supports multiple communication protocols (Ethernet, RS-232, USB) and features a resistive touch screen with 800×600 resolution, enabling seamless interaction in harsh environments. Ideal for connecting to ABB’s distributed control systems (DCS) and programmable logic controllers (PLCs), it enhances efficiency in applications ranging from process control to machine automation.
| Parameter |
Specification |
| Display |
10.4-inch TFT color touch screen (800×600 pixels) |
| Processor |
1 GHz Cortex-A9 |
| Operating System |
Windows Embedded CE 7.0 |
| Memory |
512 MB RAM, 4 GB flash storage |
| Communication Interfaces |
Ethernet, RS-232, USB 2.0 |
| Power Supply |
24 V DC (±10%) |
| Protection Class |
IP65/IP66 (front panel) |
| Operating Temperature |
-30°C to 70°C |
| Humidity |
95% non-condensing |
| Dimensions |
30.5 cm × 22.9 cm × 10.2 cm (W×H×D) |
| Weight |
2.6 kg |
PP845 3BSE042235R1
- Rugged Design: IP65/IP66-rated front panel resists dust, water, and extreme temperatures, ensuring reliability in industrial settings.
- High Performance: Fast processor and large memory enable real-time data processing and support for complex HMI applications.
- User-Friendly Interface: Intuitive touch screen with multi-language support (via Panel Builder software) simplifies operation and reduces training time.
- Flexible Connectivity: Multiple communication ports allow integration with diverse automation systems (e.g., PLCs, sensors, actuators).
- Longevity: Built with high-quality components for extended service life (e.g., 50,000+ hours of display operation).
- Advanced Functionality: Supports alarm management, trend analysis, and recipe handling for optimized process control.
- Industries: Manufacturing, energy (power generation), oil and gas, water treatment, food and beverage, pharmaceuticals.
- Use Cases:
- Chemical Reactor Control: Monitors temperature/pressure in real time and adjusts valves/actuators via touch commands.
- Robotic Assembly Lines: Controls motion sequences and displays production metrics (e.g., cycle time, error alerts).
- Building Automation: Manages HVAC systems, energy consumption, and security via centralized HMI.
Case Study: A pharmaceutical plant reduced downtime by 20% using the PP845 3BSE042235R1 to visualize batch processes, track recipe changes, and trigger predictive maintenance alerts.
Compared to similar HMI panels, the PP845 3BSE042235R1 stands out with:
- Wide Temperature Range: Operates reliably in -30°C to 70°C (versus many competitors’ 0°C to 50°C range).
- Open Architecture: Supports multi-brand controller connectivity (e.g., Siemens, Allen-Bradley) via open protocols.
- Touchscreen Durability: Resistive touch technology withstands 10+ million touches (superior to capacitive alternatives in industrial settings).
PP845 3BSE042235R1
- Compatibility: Ensure compatibility with your automation system (e.g., ABB 800xA, PLCs) and required communication protocols.
- Environment: Choose based on operating temperature, humidity, and 防护等级 (e.g., IP66 for washdown areas).
- Functionality: Evaluate screen size, memory needs, and software features (e.g., recipe management, trending).
- Budget: Balance upfront cost with long-term reliability (refurbished options available with 12-month warranties).
-
Installation: Mount in a stable environment with adequate ventilation; avoid direct sunlight.
-
Electrostatic Discharge (ESD): Use antistatic equipment during handling.
-
Software Updates: Regularly update firmware via ABB Panel Builder to access new features and security patches.
-
Maintenance: Clean the touch screen with a non-abrasive cloth; inspect cables and connections quarterly.
