PP835A 3BSE042234R2

Description

1. Product Description

2. Product Parameters

Parameter	Specification
Model	PP835A 3BSE042234R2
Display	6.5-inch TFT LCD, 640×480 pixels (WVGA)
Touch Technology	Resistive touch panel
Interfaces	Ethernet (10/100 Mbps), USB 2.0, RS-232
Power Supply	24V DC (±10%), 1.2A max.
Dimensions (W×H×D)	270 mm × 180 mm × 76.5 mm
Weight	1.48 kg
Protection Rating	IP65 (front panel), IP20 (rear)
Operating Temperature	-20°C to +60°C (ambient)
Certifications	CE, RoHS, UL 508, IEC 61131-2

PP835A 3BSE042234R2

3. Advantages and Features

• Industrial-Grade Durability:
  • IP65 rating ensures resistance to dust and water jets, withstanding high-pressure cleaning.
  • Operates in extreme temperatures (-20°C to +60°C), outperforming standard HMIs (typically -10°C to +50°C).
• Intuitive User Experience:
  • High-resolution display supports graphical workflows, recipe management, and user authentication (up to 100 user accounts).
  • Responsive touchscreen with 10-point calibration for precise control in gloves.
• Flexible Integration:
  • Native support for Modbus RTU, Profibus DP, and Ethernet/IP, reducing integration time by 25%.
  • Compatible with ABB’s Panel Builder 800 software for drag-and-drop programming (20% faster setup than code-based alternatives).
• Energy Efficiency:
  • Low power consumption (≤15W) for cost-effective operation in 24/7 environments.

4. Application Areas and Case Studies

• Industry: Automotive manufacturing, food processing, oil & gas, and water treatment.
• Use Case: ABB deployed the PP835A 3BSE042234R2 in a German automotive plant’s paint shop. The HMI controlled 50+ robotic arms, providing real-time status updates and reducing downtime by 18% through predictive maintenance alerts.

5. Competitor Comparison

Feature	PP835A 3BSE042234R2	Market Standards
Display Resolution	640×480 pixels (WVGA)	320×240 pixels (QVGA)
Temperature Range	-20°C to +60°C	0°C to +50°C
Protection Rating	IP65 (front)	IP54 (front)
Programming Time (Typical)	4 hours (Panel Builder 800)	6 hours (code-based tools)

PP835A 3BSE042234R2

6. Selection Recommendations

• Compatibility:
  • Ensure alignment with ABB PLCs (AC500, AC500-eCo) or third-party systems via Modbus/Profibus.
• Environment:
  • Choose IP65-rated models for outdoor/harsh environments; opt for smaller sizes (e.g., PP735) for space-constrained setups.
• Budget:
  • The PP835A 3BSE042234R2 offers a 15% lower lifecycle cost than premium HMIs with similar specs.

7. Precautions

• Installation:
  • Mount vertically with 20 mm clearance for ventilation; torque screws to 2.5 N·m.
  • Use shielded cables for RS-232/485 connections to prevent EMI.
• Maintenance:
  • Clean the screen with a microfiber cloth; avoid solvents.
  • Update firmware quarterly via ABB’s Panel Builder 800 to access new features.
• Safety:
  • Disconnect power before servicing; use ESD wrist straps for internal components.
