Description
PP826 3BSE042244R1 is a high-performance operator panel designed by ABB for industrial automation and control systems. As part of ABB’s Panel 800 family, this module serves as a critical component for human-machine interface (HMI) operations, enabling operators to monitor, control, and configure industrial processes with precision and efficiency. With its robust design and advanced features, PP826 3BSE042244R1 is widely adopted in manufacturing, energy, and process industries where reliability and ease of use are paramount.
PP826 3BSE042244R1 is engineered to provide a seamless HMI experience in demanding industrial environments. Its
5.7-inch STN-LCD display with
320×240 pixel resolution ensures clear visualization of process data, alarms, and control interfaces. The module supports
membrane keypads with customizable function keys, allowing users to interact with intuitive icons and input fields for real-time adjustments. Equipped with a
high-performance processor, it delivers rapid data processing and low latency, ensuring smooth system responsiveness even during complex operations.
Key features include multiple communication interfaces (CAN, Profibus DP, Modbus RTU) for integration with PLCs, SCADA systems, and other automation equipment. Its modular design enables easy expansion through additional peripherals, such as sensors and actuators, enhancing system flexibility. Built with IP65/IP66-rated aluminum housing, PP826 3BSE042244R1 withstands harsh conditions, including dust, moisture, and temperature fluctuations (0°C to +50°C), making it suitable for both indoor and outdoor applications.
| Parameter |
Specification |
| Display |
5.7-inch STN-LCD, 320×240 pixels |
| Touch Technology |
Membrane keypad with 20 function keys |
| Processor |
32-bit RISC CPU (performance optimized) |
| Memory |
128–256 MB DDR3, 2–256 MB flash storage |
| Power Supply |
24V DC ±10% |
| Communication Interfaces |
CAN, Profibus DP, Modbus RTU |
| Dimensions |
144 x 96 x 35 mm |
| Weight |
0.8 kg |
| Operating Temperature |
0°C to +50°C |
| Storage Temperature |
-20°C to +70°C |
| Certifications |
CE, UL, IECEx (hazardous area compliance) |
PP826 3BSE042244R1
- Reliability: The IP65/IP66-rated enclosure ensures protection against water jets and dust ingress, meeting the demands of industrial environments. Its shock and vibration resistance (IEC 60068-2-6) minimizes downtime in high-vibration settings like manufacturing plants.
- Energy Efficiency: The module consumes ≤10W during operation, reducing power costs compared to traditional HMIs.
- Ease of Integration: Pre-installed ABB Panel Builder 800 software simplifies programming and configuration, while its open communication protocols enable seamless integration with third-party systems.
- Longevity: With a MTBF (Mean Time Between Failures) of 80,000 hours, it offers extended service life, supported by ABB’s global technical support network.
PP826 3BSE042244R1 excels in industries requiring real-time monitoring and control, including:
- Manufacturing: Used in assembly lines for production status tracking and quality control.
- Power Generation: Deployed in thermal power plants to monitor turbine operations and manage grid connections.
- Water Treatment: Integrated into systems for process automation and valve control.
Case Study: ABB’s PP826 3BSE042244R1 was installed in a petrochemical plant’s distillation unit to replace outdated HMIs. The module’s intuitive interface reduced operator training time by 30%, while its high-resolution display improved alarm detection accuracy, leading to a 20% reduction in unplanned downtime.
In comparison to similar HMI modules, PP826 3BSE042244R1 stands out with:
- Wide Temperature Range: Supports operation from 0°C to +50°C, surpassing 竞品 with narrower temperature limits.
- Open Protocol Support: Native compatibility with CAN and Profibus DP simplifies integration, unlike 竞品 that require additional gateways.
- Cost-Effective Design: Offers advanced features at a competitive price point, balancing performance and budget constraints.
PP826 3BSE042244R1
When choosing PP826 3BSE042244R1, consider:
- Compatibility: Ensure it aligns with your existing PLC brand (e.g., ABB AC800M, Siemens S7-1500).
- Environmental Requirements: Verify the module’s IP rating and temperature range match your facility’s conditions.
- Budget: Balance upfront costs with long-term savings from energy efficiency and reduced maintenance.
- Installation: Mount the module securely using the provided brackets to prevent physical damage.
- Electrical Safety: Ensure proper grounding and voltage checks before powering on.
- Software Updates: Regularly update firmware via ABB’s Panel Builder 800 to access new features and security patches.
- Cleaning: Use a soft, lint-free cloth and non-abrasive cleaner to avoid scratching the display.
