PM511V08 3BSE011180R1

Description

ABB PM511V08 3BSE011180R1 is a high-performance industrial automation processor module with the following details:

ABB PM511V08 3BSE011180R1 Product description

The ABB PM511V08 3BSE011180R1 is a high-performance processor module designed for industrial automation and belongs to the Advant OCS family. The module is mainly used in process control, data acquisition and transmission, equipment control and other scenarios, with high reliability, flexibility and scalability, suitable for harsh industrial environments.

Product parameter

Processor type: High performance industrial-grade processor (such as Motorola 68040 or V08).

Memory configuration:

8MB dynamic RAM with ECC check.

Expandable storage module (such as PCMCIA slot).

Input voltage: 24 VDC, some data mentioned support 19.2-31.2 VDC or 5V/24V.

Operating temperature range: -20°C to +60°C, some data mention -40°C to +70°C.

Size: 150x100x230mm or 220x110x50mm.

Weight: about 1.2kg or 2kg.

Communication interface:

RS-485, Ethernet, Profibus DP, etc.

Multiple communication protocols and device managers are supported.

Other features:

High precision computing capability.

Support multi-channel analog signal input and output.

Provides human machine interaction interface (HMI).

Product specification

Protection class: IP65.

Operating humidity range: 20% to 90%RH.

Power supply: 0.5A (some data mention that the maximum load current is 8A).

series

The product is part of ABB’s Advant OCS family and is part of the Advant Controller 31 family.

trait

High performance processing capability: can quickly process complex control algorithms, improve system response speed and stability.

High reliability: Industrial design, anti-interference and stability.

Modular design: easy to install, maintain and expand.

Rich interface support: supports a variety of communication protocols and extension modules.

Man-machine interaction function: provides intuitive user interface, convenient operator monitoring and control.

Function and use

Process control: used for real-time control of temperature, pressure, flow and other parameters.

Data acquisition and processing: Collect and analyze the field equipment data.

Equipment control: Industrial equipment is controlled by logic program.

Fault diagnosis: With self-diagnosis function, timely detection and reporting of faults.

Application field

ABB PM511V08 3BSE011180R1 is widely used in the following fields:

Chemical industry: process control, data acquisition.

Metallurgical industry: Process control, energy management.

Power and Energy: Power generation, transmission and distribution systems.

Manufacturing: Automatic control of production lines.

Water treatment industry: Monitoring and control.
