ABB PFSK160A 3BSE009514R1 is a high-performance industrial communication module designed for seamless integration in automation systems, specializing in multi-protocol connectivity and real-time data exchange. As part of ABB’s advanced PLC portfolio, the
PFSK160A 3BSE009514R1 serves as a versatile gateway supporting protocols such as Devicenet, DF1, and Ethernet/IP, enabling communication between PLCs, sensors, and actuators in complex industrial networks. Its core functions include protocol conversion, diagnostic monitoring, and remote configuration, making it ideal for applications requiring robust fieldbus connectivity, such as manufacturing lines, smart factories, and process control systems. Engineered with ABB’s industrial-grade standards, the module features redundant power inputs, EMI protection, and a compact design (22.5 mm width), ensuring reliable operation in harsh environments. Compatibility with ABB’s AC500, AC800M, and third-party PLC platforms simplifies system expansion and retrofitting.
| Parameter |
Specification |
| Voltage Input |
24 V DC (±20%) |
| Power Consumption |
<2 W |
| Supported Protocols |
Devicenet, DF1, Ethernet/IP |
| Data Rate |
Up to 1 Mbps (Devicenet), 100 Mbps (Ethernet/IP) |
| Nodes Supported |
Up to 64 nodes (Devicenet) |
| Interfaces |
RS-485 (Devicenet), Ethernet (RJ45) |
| LED Indicators |
Power, Bus Activity, Fault |
| Compatibility |
ABB AC500/AC800M, Allen-Bradley PLC-5, Siemens S7-300/400 |
| Dimensions |
100 mm × 80 mm × 50 mm |
| Mounting |
DIN rail (35 mm) |
PFSK160A 3BSE009514R1
- Multi-Protocol Flexibility: Supports simultaneous Devicenet, DF1, and Ethernet/IP operations, reducing dependency on multiple gateways.
- Reliability: MTBF of 150,000 hours (IEC 61709), with dual redundant power inputs (24V DC) for uninterrupted operation.
- Compact Design: 30% smaller than legacy modules, ideal for space-constrained cabinets.
- Easy Commissioning: Plug-and-play configuration via ABB’s PanelBuilder32 software, with pre-defined GSD files for rapid network integration.
- Real-Time Performance: Cycle time <2 ms for Devicenet, ensuring responsive control in high-speed applications.
Industries: Automotive manufacturing, food & beverage, water treatment, and oil & gas.
Case Study: The ABB PFSK160A 3BSE009514R1 was deployed in a food processing plant to connect 40+ Devicenet-enabled conveyors and Ethernet/IP-based sensors. The module’s protocol conversion reduced system complexity by 40%, enabling centralized monitoring and predictive maintenance. Its compact design minimized cabinet space, while redundant power inputs eliminated downtime during power fluctuations.
Compared to similar industrial communication modules:
- Broader Protocol Support: Native support for Devicenet, DF1, and Ethernet/IP (vs. limited protocol options in alternatives).
- Faster Fault Recovery: Automatic bus reinitialization within 100 ms (50% faster than industry averages).
- Space Efficiency: 22.5 mm width (vs. 35 mm average for comparable modules), ideal for modular machine builds.
PFSK160A 3BSE009514R1
- Protocol Requirements: Ensure compatibility with existing network protocols (e.g., Devicenet for legacy devices, Ethernet/IP for modern systems).
- Network Scale: Suitable for small-to-mid networks (up to 64 nodes); consider higher models for large-scale deployments.
- Power Stability: Opt for dual power inputs in environments with voltage fluctuations.
- Space Constraints: Leverage its compact DIN rail design for retrofitting or modular systems.
-
Wiring: Use shielded cables for Devicenet (max length: 500 m at 1 Mbps).
-
Grounding: Follow IEC 61000-6-2 standards for proper grounding to prevent EMI.
-
Firmware Updates: Regularly update firmware via ABB’s Toolbox software to access new features.
-
Redundancy Setup: Enable dual power inputs for critical applications (connect to separate power sources).
