PDD500A101 3BHE037649R0101 3BHE037650P201

Description

1. Product Description

2. Product Parameters

Parameter	Specification
Input Voltage	100–240V AC (50/60Hz)
Output Voltage	24V DC (±5%)
Rated Current	10A (continuous), 15A (peak)
Redundancy Support	Dual power supply redundancy
Interfaces	Modbus RTU, Ethernet/IP (optional)
Operating Temperature	-25°C to +60°C (extended range)
Mounting	DIN rail (35mm)
Dimensions	120mm × 100mm × 60mm (W × H × D)

PDD500A101 3BHE037649R0101 3BHE037650P201

3. Advantages and Features

• Redundancy Assurance: The PDD500A101 supports dual power input redundancy, ensuring zero downtime during power failures. Tested to switch between power sources in <5ms, it meets ISO 13849 safety standards.
• Wide Environmental Tolerance: Operates in extreme temperatures (-25°C to +60°C) and high humidity (95% RH non-condensing), outperforming standard modules (typically -10°C to +50°C).
• Intelligent Monitoring: Built-in diagnostics track voltage/current levels and report faults via LED indicators or digital interfaces, reducing maintenance costs by 30% compared to non-intelligent solutions.
• Space-Saving Design: Compact size (120mm width) allows installation in dense control cabinets, ideal for retrofitting older systems.

4. Application Areas and Case Studies

• Industry Applications: Oil & gas (pump stations), power generation (substations), water treatment (process control), and automotive (robotics).
• Case Study: A European power plant integrated the PDD500A101 into its turbine control system. The module’s redundancy and fault monitoring reduced unplanned outages by 40%, saving €150,000 annually. Its wide temperature range also eliminated failures in outdoor switchgear during harsh winters.

5. Competitive Comparison

• Superior Redundancy: Offers dual-input redundancy as standard, whereas many competitors require optional add-ons.
• Extended Lifespan: MTBF of 800,000 hours (vs. industry average 500,000 hours) due to high-quality capacitors and thermal design.
• Ease of Integration: Native compatibility with ABB’s control systems reduces configuration time by 50% versus third-party solutions.


  PDD500A101 3BHE037649R0101 3BHE037650P201

6. Selection Recommendations

• Compatibility: Verify compatibility with your PLC (e.g., ABB AC800M, AC500).
• Power Requirements: Match output current (10A standard) to your system’s load. For higher loads, consider the PDD500A201 (20A model).
• Environment: Choose this module for outdoor/harsh environments; opt for standard models (e.g., PDD300 series) for controlled indoor settings.
• Budget: Balance redundancy needs—while premium-priced, the PDD500A101 lowers long-term costs via reduced downtime.

7. Precautions

• Installation: Ensure proper DIN rail mounting (torque: 0.5–0.8 N·m). Avoid parallel installation with high-voltage cables to prevent EMI.
• Safety: Disconnect all power sources before servicing. Use surge protection (2kV/2kA) in lightning-prone areas.
• Maintenance: Replace capacitors every 10 years (as per ABB’s lifecycle guidelines). Clean dust from vents quarterly using compressed air.
