PCD231B101

Description

ABB PCD231B101 is a high-performance control module that is widely used in industrial automation, robot control and power system monitoring. Here is a detailed description of the product:

ABB PCD231B101 Product description

ABB PCD231B101 is a high-performance control module designed for generator excitation systems. Its main function is to regulate the output voltage and power of the equipment by precisely controlling the excitation current, thus ensuring stable and efficient operation of the equipment under various operating conditions.

Product parameter

Input voltage: 85~264VAC (some evidence shows 24VDC).

Output voltage: 0~10VDC.

Input current: 500mA or 5A.

Output power: 360W.

Operating temperature range: -25℃~+70℃.

Storage temperature range: -40 ° C to +85 ° C

Dimensions: 115mm x 48mm x 150mm.

Weight: About 1.2kg.

Protection class: IP30.

Communication interface: Supports Modbus, Profibus, RS485, etc.

Product specification

Series: The PCD231B101 is part of the ABB Excitation controller module and is suitable for the excitation control of synchronous and asynchronous generators.

Features:

High precision control (±0.1% accuracy).

Fast response time (milliseconds).

Multi-channel control.

Supports over current, over voltage, under voltage, and magnetic loss protection.

Series and model

PCD231B101 belongs to ABB’s power electronics family of control modules, the specific model is PEC80-CCI.

trait

High-performance processor: Uses high-performance microprocessor to support high-speed computing and complex data processing.

Flexible configuration: Support programmable logic control, users can customize programming according to requirements.

Durable: Industrial design, strong anti-interference ability, suitable for harsh environment.

Ease of use: Provides a user-friendly interface and intuitive menu configuration.

Function and use

The main functions of PCD231B101 are:

Monitor and control generator excitation current and voltage.

Improve the efficiency and performance of the motor.

Stabilize power grid voltage and current.

Realize real-time monitoring and control of industrial processes.

Application field

PCD231B101 is widely used in the following areas:

Power plant: Used for stable operation of generator excitation system.

Industrial automation: for process control and monitoring.

Robot control: Improve the stability and efficiency of robotic systems.

Power system monitoring: for the stability of grid voltage and current.

Other industrial applications: such as building automation, environmental monitoring, traffic signal systems, etc.
