GVC736CE101 3BHE039203R0101 5SXE12-0184

Description

Deep analysis of ABB GVC736CE101 3BHE039203R0101 5SXE12-0184 IGCT module

Product Overview

ABB GVC736CE101 3BHE039203R0101 5SXE12-0184 is a high-performance IGCT(Insulated Gate Bipolar Transistor)module produced by ABB.IGCT is a high-power semiconductor device with characteristics such as fast switching,high voltage resistance,and high current,widely used in the field of power electronics.This module is typically integrated into ABB’s frequency converters,inverters,or other power electronic devices as a core power component.

Product Features

High power density:capable of handling high currents and high power,suitable for high-power applications.

Quick switch:With fast switching speed,it can achieve efficient power conversion.

High reliability:Designed for industrial environments,it has high reliability and durability.

Low loss:The conduction voltage is reduced,the conduction loss is small,and the efficiency of the system is improved.

Modular design:easy to install and maintain.

Product parameters and specifications

Rated current:The maximum current that a module can continuously withstand.

Rated voltage:The maximum voltage that a module can withstand.

Switching speed:the switching time of the module.

Voltage drop during conduction:The voltage drop when a module is conducting.

Junction temperature:The maximum junction temperature allowed by the module during operation.

Packaging form:The external dimensions and packaging method of the module.

Product series

GVC736CE101 belongs to a series of IGCT modules from ABB.ABB offers multiple models of IGCT modules to meet different power levels and application requirements.

Product function and purpose

Power electronic equipment:As a core power device,it is applied in various power electronic devices,such as frequency converters,inverters,DC drive systems,etc.

Industrial automation:used to control motors,heating equipment,lighting equipment,etc.,to achieve automated production.

Power system:applied to power conversion,reactive power compensation,etc.in the power system.

New energy:applied in new energy fields such as wind power generation and photovoltaic power generation.

application area

Metallurgy:Used for controlling equipment such as electric arc furnaces and steel mills.

Petrochemical:Used for driving equipment such as compressors and pumps.

Electricity:Used for traction substations,flexible transmission systems,etc.in the power system.

Ship:Used for ship propulsion systems.

Other industrial fields:widely used in industrial fields that require high-power power conversion.

summary

ABB GVC736CE101 3BHE039203R0101 5SXE12-0184 is a high-performance IGCT module widely used in the field of power electronics.
