ABB CI930F 3BDH001010R0005 is a high-performance
Ethernet communication interface module designed for ABB’s AC 800M distributed control system (DCS), serving as a critical gateway for industrial automation networks. As part of the
CI900 series, this module is engineered to enable seamless data exchange between the control system, field devices, and higher-level supervisory systems, supporting real-time communication in complex industrial environments. The
CI930F 3BDH001010R0005 specializes in Ethernet-based protocols, making it ideal for integrating with modern IIoT platforms, SCADA systems, and third-party devices in smart factory applications.
Featuring a dual-core processor and advanced networking capabilities, the ABB CI930F 3BDH001010R0005 supports protocols such as PROFINET, Modbus TCP, and Ethernet/IP, with data transfer rates up to 1 Gbps. Its core functions include protocol conversion, data routing, and security filtering, ensuring reliable and secure transmission of control commands, process data, and diagnostic information. Positioned as a backbone component for industrial digitization, the module enhances system scalability by enabling remote monitoring, predictive maintenance, and centralized management via ABB’s 800XA Extended Automation System. By reducing latency and improving interoperability, the CI930F 3BDH001010R0005 drives operational efficiency and supports the transition to Industry 4.0 architectures.
| Parameter Name |
Parameter Value |
| Product Model |
CI930F 3BDH001010R0005 |
| Manufacturer |
ABB |
| Product Type |
Ethernet Communication Module |
| Supported Protocols |
PROFINET, Modbus TCP, Ethernet/IP, OPC UA |
| Data Rate |
10/100/1000 Mbps (auto-negotiation) |
| Physical Interfaces |
2x RJ45 (1 Gbps), 1x USB (configuration) |
| Power Supply |
24 V DC (redundant supply supported) |
| Operating Temperature |
-40°C to +70°C |
| Dimensions (W×H×D) |
45 mm × 177 mm × 150 mm |
| Mounting Method |
DIN rail (AC 800M backplane) |
| Redundancy Support |
Dual module redundancy (active/standby) |
| Cybersecurity Features |
IEC 62443 compliance, encrypted communication |
| Certification |
CE, UL, CSA, PROFINET Conformance Tested |
CI930F 3BDH001010R0005
The ABB CI930F 3BDH001010R0005 distinguishes itself through its advanced networking capabilities and industrial-grade security. Its dual-port Ethernet interface supports ring topology configurations, enhancing network redundancy and fault tolerance in mission-critical systems. The module’s built-in firewall and secure boot functionality comply with IEC 62443 standards, protecting against unauthorized access and cyber threats—a critical feature for infrastructure in energy, pharmaceuticals, and automotive sectors.
A key advantage is the CI930F 3BDH001010R0005’s compatibility with ABB’s Control Builder M software, which simplifies configuration of IP addresses, subnet masks, and protocol parameters. The module’s real-time diagnostics provide granular insights into network health, including packet loss, latency, and device connectivity, enabling proactive troubleshooting and reducing downtime. The hot-swappable design allows for module replacement without disrupting system operations, ensuring continuous availability in 24/7 production environments.
The module’s high-speed data processing capabilities make it suitable for applications requiring rapid data exchange, such as robotics, high-frequency trading systems, and real-time analytics. Its support for OPC UA enables seamless integration with cloud platforms, facilitating remote monitoring via ABB Ability™ and other IIoT solutions.
The ABB CI930F 3BDH001010R0005 is widely deployed in industries undergoing digital transformation. In manufacturing, it connects PLCs, robots, and smart sensors to a central SCADA system, enabling real-time tracking of production KPIs and predictive maintenance of machinery. For energy and utilities, the module supports remote monitoring of power plants, renewable energy farms, and oil/gas pipelines via PROFINET, ensuring grid stability and rapid response to faults.
In pharmaceutical and food processing, the CI930F 3BDH001010R0005 ensures compliance with regulatory requirements by securely transmitting process data to quality control systems. It also excels in logistics and warehousing, where it coordinates automated guided vehicles (AGVs), conveyor systems, and warehouse management software via Ethernet/IP, optimizing material flow and inventory accuracy.
By addressing the challenges of network complexity, cybersecurity, and data integration, the module helps customers future-proof their automation systems. Its versatility across protocols and industries makes it a strategic investment for organizations aiming to enhance operational agility and leverage data-driven insights.
- ABB CI920F 3BDH001009R0005: A predecessor model with 10/100 Mbps capabilities, suitable for legacy systems.
- ABB CI858-1 3BSE018137R1: A complementary module for PROFINET/Modbus TCP in smaller systems, often used alongside the CI930F in hybrid networks.
- ABB PM866AK01 3BSE066503R1: A control processor module that pairs with the CI930F to execute advanced control logic.
- ABB S800 I/O Modules: Distributed I/O systems (e.g., DI810, AO810) that rely on the CI930F for Ethernet connectivity.
- ABB 800XA Gateway: A software solution that integrates with the CI930F to enable cloud-based analytics and remote diagnostics.
- ABB TB840: A terminal block module for field device wiring, compatible with the CI930F’s I/O expansion capabilities.
CI930F 3BDH001010R0005
Pre-installation preparation: Mount the ABB CI930F 3BDH001010R0005 on the AC 800M backplane, ensuring proper alignment with the controller and other modules. Connect Ethernet cables using shielded twisted-pair (STP) wiring to minimize EMI, and configure the module’s IP address and protocol settings via Control Builder M. For redundant setups, install a second CI930F module and enable active/standby redundancy in the software.
Maintenance recommendations: Regularly monitor the module’s status LEDs and network diagnostics for alerts on communication errors or security threats. Update firmware quarterly to incorporate the latest protocol updates and cybersecurity patches. Clean the module’s ventilation slots to prevent dust accumulation, and verify that the operating temperature remains within specified limits. In redundant systems, test failover functionality during scheduled outages to ensure reliability. For hardware issues, replace the module with a pre-configured spare to minimize downtime, ensuring the new unit is synchronized with the control system’s network settings.
ABB stands behind the CI930F 3BDH001010R0005 with a comprehensive quality assurance program, including rigorous testing for EMC compliance, protocol conformance, and cybersecurity resilience. The module is backed by a standard [X-year] warranty, covering defects in materials and workmanship. ABB’s global technical support team provides 24/7 assistance for network configuration, troubleshooting, and remote health monitoring via ABB Ability™. Customers can access detailed documentation, training modules, and simulation tools to maximize the module’s capabilities, ensuring long-term reliability and performance in industrial Ethernet applications.
