Product Overview
The ABB CI810B 3BSE020520R1 is a sophisticated fieldbus communication interface module that plays a pivotal role in industrial automation systems. As part of ABB’s advanced Advant OCS and 800xA platforms, this module is designed to establish seamless communication between the control system and the field devices connected via the AF100 fieldbus network. The CI810B 3BSE020520R1 is engineered to enhance the connectivity and data exchange capabilities within distributed control setups, making it an essential component for industries such as manufacturing, power generation, and process control.
Featuring two integrated AF100 twisted pair modems, the CI810B 3BSE020520R1 enables efficient transmission of data between the control system and the fieldbus. It comes with a comprehensive set of accessories including a power supply connector (3BSC840098R1), a TB807 module bus terminator (3BSE008538R1), and two terminal blocks (3BSC840098R1). The module also has the basic system software version 1.5 pre – loaded, which allows for quick and easy integration into existing systems. Its compact and robust design ensures reliable performance even in harsh industrial environments, while its high – speed data transfer capabilities support real – time monitoring and control of industrial processes.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | CI810B 3BSE020520R1 |
| Manufacturer | ABB |
| Product Type | Fieldbus Communication Interface Module |
| Fieldbus Type | AF100 |
| Modems Included | 2 AF100 twisted pair modems |
| Power Supply Connector | 1 piece of 3BSC840098R1 |
| Module Bus Terminator | 1 piece of 3BSE008538R1 (TB807) |
| Terminal Blocks | 2 pieces of 3BSC840098R1 |
| Pre – loaded Software | Basic system software version 1.5 |
| AF100 Connector | 3BSC840105R1 |
| Dimensions (W×H×D) | 158 mm×250 mm×87 mm |
| Weight | 0.5 kg |
| RoHS Status | Compliant with EU directive 2011/65/EU |
| WEEE Category | 5. Small equipment (no external dimension more than 50 cm) |
| Number of Batteries | 0 |
CI810B 3BSE020520R1
Main Features and Advantages
Robust Fieldbus Connectivity
The CI810B 3BSE020520R1’s dual AF100 twisted pair modems offer reliable and high – speed communication over the AF100 fieldbus network. This allows for seamless integration of a wide range of field devices, such as sensors, actuators, and other intelligent devices, into the overall control system. In a large – scale manufacturing plant, for example, the module can effectively handle the data exchange between hundreds of sensors on the production line and the central control unit, ensuring smooth operation and accurate monitoring of the manufacturing process.
Comprehensive Accessory Package
With the inclusion of a power supply connector, a module bus terminator, and two terminal blocks, the installation process of the CI810B 3BSE020520R1 is significantly simplified. These accessories are specifically designed to work in harmony with the module, reducing the need for additional components and minimizing potential compatibility issues. This not only saves installation time but also enhances the overall reliability of the connection.
Pre – loaded Software for Quick Deployment
The pre – loaded basic system software version 1.5 enables rapid deployment of the CI810B 3BSE020520R1 in industrial settings. Engineers can quickly configure the module to suit the specific requirements of the application, without having to spend time on software installation and initial setup. This is particularly beneficial for projects with tight schedules or for retrofitting existing systems, as it allows for a faster transition to the new communication infrastructure.
Compact and Durable Design
Measuring 158 mm in width, 250 mm in height, and 87 mm in depth, the CI810B 3BSE020520R1 has a compact form factor that fits easily into standard control panels. Its rugged construction, compliant with RoHS standards, makes it suitable for use in harsh industrial environments, including those with high levels of dust, humidity, or electromagnetic interference. This ensures long – term reliable operation, reducing maintenance costs and downtime.
CI810B 3BSE020520R1
Application Field
The ABB CI810B 3BSE020520R1 finds extensive use across various industries:
- Manufacturing: In automotive manufacturing plants, the module connects sensors and actuators on the assembly line to the central control system. It enables real – time monitoring of the production process, such as tracking the position of robotic arms, the status of conveyor belts, and the quality of products being assembled. This helps in optimizing production efficiency, reducing errors, and ensuring high – quality output.
- Power Generation: In thermal power plants, the CI810B 3BSE020520R1 is used to communicate with field devices like temperature sensors, pressure gauges, and valve actuators. It plays a crucial role in monitoring and controlling the power generation process, ensuring stable power output and safe operation of the plant. For example, it can transmit data on the temperature of the boiler to the control system, allowing for timely adjustments to prevent overheating.
- Process Control: In chemical plants, the module is essential for connecting different process control devices. It enables the control system to receive data from flow meters, pH sensors, and level sensors, and send control signals to pumps, valves, and mixers. This ensures accurate control of chemical reactions, maintaining product quality and process safety.
Related Products
- ABB CI854B 3BSE020524R1: A more advanced communication interface module with additional features, suitable for applications that require higher data transfer rates and more complex network configurations. It can handle a larger number of field devices and offers enhanced diagnostic capabilities compared to the CI810B 3BSE020520R1.
- ABB TB807 3BSE008538R1: The module bus terminator that comes as part of the CI810B 3BSE020520R1 package. While the CI810B 3BSE020520R1 includes one such terminator, having spare TB807 units can be useful for system expansion or replacement in case of failure.
- ABB 3BSC840098R1: The power supply connector and terminal blocks included with the CI810B 3BSE020520R1. Spare 3BSC840098R1 connectors and terminal blocks can be stocked for maintenance purposes, ensuring quick replacement in case of damaged or faulty components.
- ABB AF100 3BSC840105R1: The AF100 connector that is part of the CI810B 3BSE020520R1 setup. Similar to other accessories, having extra AF100 connectors can be beneficial for system upgrades or when dealing with connection issues.
- ABB AC 800M Control System: The overall control system in which the CI810B 3BSE020520R1 is integrated. The AC 800M system provides the central processing and management capabilities, while the CI810B 3BSE020520R1 serves as a key interface for communication with field devices.
Installation and Maintenance
Pre – installation preparation: Before installing the CI810B 3BSE020520R1, ensure that the control panel has sufficient space to accommodate its dimensions of 158 mm×250 mm×87 mm. Check the compatibility of the module with the existing control system and the AF100 fieldbus network. Mount the module securely on the DIN rail in the control panel. Connect the power supply connector (3BSC840098R1) to the appropriate power source, following the electrical safety guidelines. Install the TB807 module bus terminator (3BSE008538R1) at the end of the module bus as per the system requirements.
Maintenance recommendations: Regularly inspect the CI810B 3BSE020520R1 for any signs of physical damage, such as cracks or loose connections. Monitor the communication status of the module through the control system’s diagnostic tools. Check for any error messages related to the module, which could indicate issues with the fieldbus connection, power supply, or software. Periodically clean the module to remove dust and debris, especially in dusty industrial environments. If any components like the power supply connector, terminal blocks, or the module itself show signs of wear or malfunction, replace them with genuine ABB spare parts to ensure continued reliable operation.
