BENTLY 1900/65A-00-00-01-00-00 Compact Vibration Monitoring Module

1. Product Description

• Single-Channel Monitoring: Supports one input channel for vibration velocity or acceleration measurement, compatible with IEPE accelerometers or magnetoelectric velocity sensors.
• Real-Time Signal Conditioning: Features a 4–20 mA analog output for continuous vibration amplitude transmission, enabling seamless integration with PLC/DCS systems for real-time monitoring.
• Rugged Design for Harsh Environments: Operates reliably in temperatures ranging from -40°C to +85°C and resists electromagnetic interference (EMI), making it suitable for challenging industrial settings like manufacturing plants, power substations, or wastewater facilities.
• User-Friendly Configuration: Simple setup via front-panel dip switches or optional software, with LED indicators for quick status checks, reducing commissioning time and technical complexity.

2. Technical Parameters

Parameter	Specification
Brand	BENTLY
Model	1900/65A-00-00-01-00-00
Module Type	Compact vibration monitoring (1 channel)
Input Sensors	IEPE accelerometers (±50 g) or velocity sensors (0–200 mm/s)
Frequency Range	0.5 Hz to 10 kHz (velocity), 2 Hz to 10 kHz (acceleration)
Output Signal	1x 4–20 mA analog (vibration amplitude)
Power Supply	24 VDC ±15% (nominal)
Power Consumption	<3 W
Operating Temperature	-40°C to +85°C (-40°F to +185°F)
Mounting	DIN rail or panel mount (compact 100 mm x 80 mm x 50 mm)
Compatibility	PLC/DCS systems (e.g., Siemens, Allen-Bradley), Bentley 1900 Series accessories
Certifications	CE, RoHS, IEC 61000-4-2 (EMC compliance)

1900/65A-00-00-01-00-00

3. Advantages and Features

• Cost-Effective Simplicity: Offers essential vibration monitoring at 40% lower cost than premium modules, ideal for non-critical equipment or small-scale installations while maintaining ±1.5% measurement accuracy.
• Space-Saving Design: At 60% smaller than traditional rack-mounted solutions, it fits seamlessly into compact control panels or remote locations with limited space, reducing installation costs by 25%.
• Reliability in Demanding Conditions: Field-proven to withstand 5g peak vibrations and extreme temperatures, ensuring consistent performance in environments where generic sensors fail.
• Plug-and-Play Integration: Requires no additional signal conditioners for IEPE or velocity sensors, simplifying wiring and setup for technicians with basic training.

4. Application Areas and Case Study

Application Areas:

• Manufacturing: Monitoring conveyor belts, mixers, and small-scale production machinery to prevent unexpected downtime.
• Energy: Tracking vibrations in auxiliary pumps, fans, and generators in thermal or renewable energy plants.
• Water/Wastewater: Ensuring reliability of pumps and blowers in treatment facilities, critical for continuous operation.

Case Study:

5. Competitive Comparison

• Dual Sensor Compatibility: Supports both accelerometers and velocity sensors natively, offering flexibility unmatched by many single-input competitors.
• Wide Temperature Range: Operates across a broader thermal spectrum than most budget models, reducing the need for costly environmental enclosures in extreme climates.
• Proven Durability: Features a mean time between failures (MTBF) of 150,000 hours, outlasting generic alternatives by 30% in harsh industrial settings.


  1900/65A-00-00-01-00-00

6. Selection Recommendations

• Equipment Type: Choose the 1900/65A-00-00-01-00-00 for single-point monitoring of low to medium-speed machinery (up to 8,000 RPM), such as fans or small pumps. For multi-point or high-speed applications, consider dual-channel models like the 1900/65A-00-00-02-00-01.
• Environmental Factors: Prioritize this model for installations with moderate vibration (≤5g) and temperature fluctuations, as its compact design balances cost and resilience.
• System Requirements: Ensure your control system accepts 4–20 mA analog inputs; for digital communication, inquire about optional upgrade kits (not included in this model).
• Budget Constraints: Ideal for projects requiring basic vibration monitoring without advanced analytics, offering a cost-efficient entry into predictive maintenance.

7. Precautions

• Installation:
  • Mount the module away from high-voltage cables to minimize EMI; use shielded twisted-pair cables for sensor connections to maintain signal integrity.
  • Align sensors perpendicular to the machinery surface and calibrate using a vibration shaker to establish accurate baseline readings.
• Configuration:
  • Set vibration thresholds according to ISO 1940 (bearing vibration standards) or the equipment manufacturer’s guidelines to avoid false alarms.
  • Verify the 4–20 mA output range during commissioning to ensure compatibility with your PLC/DCS input settings.
• Maintenance:
  • Regularly inspect the module’s LED indicators for power and signal status, and clean dust or debris from ventilation slots in high-dust environments.
  • Replace the module every 10 years or after exposure to extreme conditions to maintain measurement accuracy.
• Safety:
  • Power down the system before installing or servicing the module to prevent electrical hazards.
  • In hazardous environments, use approved explosion-proof enclosures and follow local safety standards (e.g., NEC Class I, Division 2).
