AO810 3BSE008522R1

Description

1. Product Description

2. Product Parameters

Parameter	Specification
Model	AO810 3BSE008522R1
Brand	ABB
Type	Analog Output Module
Channels	8 isolated channels
Output Range	4–20 mA (default), 0–20 mA, 0–10 V
Accuracy	±0.1% of full scale
Update Time	≤5 ms per channel
Voltage Supply	24 V DC (19.2–28.8 V DC)
Current Consumption	≤50 mA (excluding output load)
Compatibility	ABB AC500, AC500-ECO, and 第三方 PLC systems
Dimensions	100 mm (W) × 110 mm (H) × 110 mm (D)
Weight	~200 g

AO810 3BSE008522R1

3. Advantages and Features

• High Precision: ±0.1% accuracy ensures precise control of analog devices, reducing process variability.
• Fast Response: ≤5 ms update time supports real-time adjustments in dynamic systems.
• Isolated Channels: 8 isolated outputs prevent signal interference, enhancing reliability.
• Diagnostic Capabilities: Built-in short-circuit and overload protection with LED status indicators.
• Modular Design: Easy integration with ABB’s PLC platforms, simplifying system expansion.
• Energy Efficiency: Low power consumption (≤50 mA) reduces operational costs.

4. Application Areas and Use Cases

• Industries: Manufacturing, energy (oil/gas, power plants), water treatment, and chemical processing.
• Scenarios: Control of valves, actuators, motors, and heaters in process automation.
• Use Case: A food and beverage facility used the AO810 3BSE008522R1 to regulate steam flow in a pasteurization line, achieving ±0.5°C temperature stability and compliance with hygienic standards.

5. Competitor Comparison

• Superior Accuracy: ±0.1% vs. typical ±0.2% in 竞品 modules.
• Faster Update Rates: ≤5 ms vs. 10–20 ms in comparable solutions.
• Integrated Diagnostics: Real-time fault detection reduces downtime by 30% compared to non-diagnostic modules.
• Wide Voltage Range: 19.2–28.8 V DC compatibility vs. restrictive 24 V DC-only options in some alternatives.


  AO810 3BSE008522R1

6. Selection Recommendations

• Compatibility: Ensure compatibility with your PLC system (e.g., ABB AC500 series).
• Channel Requirements: Choose 8-channel configuration for medium-scale applications; scale up/down with ABB’s modular I/O range.
• Environment: Rated for -25°C to +60°C operation; suitable for harsh industrial settings.
• Budget: Balances performance (high accuracy/diagnostics) with cost-effectiveness compared to premium-tier modules.

7. Precautions

• Installation: Follow ABB’s wiring guidelines (shielded cables for analog signals).
• Safety: Disconnect power before module installation/removal.
• Maintenance: Regularly inspect for loose connections; replace modules if diagnostic LEDs indicate faults.
• Environmental Compliance: RoHS-compliant; avoid exposure to liquids or corrosive gases.
