Product Description of ABB TU810V1 Compact Module Terminal Unit

Product Overview

ABB TU810V1 is a compact Module Termination Unit(MTU)primarily used in ABB S800 I/O systems.It serves as a connecting bridge between I/O modules and field devices,responsible for transmitting field signals to the I/O modules while providing electrical isolation and signal conversion functions.TU810V1 has the characteristics of compact structure,easy installation,and high reliability,and is widely used in the field of industrial automation.

Product Features

Compact design:With a compact structure,it saves installation space.

Modular design:It can be flexibly expanded to meet the needs of different I/O points.

Electrical isolation:Provide reliable electrical isolation to protect I/O modules and on-site equipment.

Signal conversion:It can achieve the conversion between different types of signals.

Easy to install:Easy to install and simple to maintain.

High reliability:Using high-quality materials and processes,it has high reliability.

Product parameters

Number of signal terminals:16

Rated insulation voltage:50V

Working temperature:-20℃~+60℃

Working humidity:5%~95%RH

Size;Approximately 100mm x 100mm x 50mm

Weight:Approximately 0.5kg

Product specifications

Shell material:metal

Protection level:IP30

Installation method:DIN rail

Product series

TU810V1 is a modular component of ABB S800 I/O system,used in conjunction with S800 series I/O modules to form a complete I/O system.

Product function

Signal connection:Connect the signals of on-site devices to the I/O module.

Electrical isolation:Provide electrical isolation to protect I/O modules and field devices.

Signal conversion:Implement the conversion between different types of signals.

Signal allocation:Allocate signals to multiple I/O modules.

Product Usage

Industrial automation:widely used in automation control systems for various industrial processes,such as chemical,metallurgical,power,etc.

Process control:used to connect various sensors and actuators to measure and control process variables.

Data collection:used to collect on-site data and transmit it to the upper computer.

application area

Process control system:As a component of the I/O system,it is used to connect field devices and control systems.

Distributed Control System:Used to build a distributed control system that enables centralized control of multiple devices.

SCADA system:used to connect on-site equipment and SCADA system,to achieve monitoring and management of processes.

summary

ABB TU810V1 is a highly reliable and easy-to-use module terminal unit that plays an important role in the ABB S800 I/O system.It can effectively connect field devices and I/O modules,providing reliable data transmission and signal conversion functions for industrial automation systems.
