ABB TC514V2

Description

1. Product Description

2. Product Parameters

• Power Supply: 24V DC
• Rated Isolation: 50V
• Dimensions: Length 168mm × Height 122mm × Width 58mm
• Net Weight: 0.34kg
• Environmental Status: Complies with EU Directive 2011/65/EU (RoHS)
• WEEE Category: Category 5 (Small equipment with external dimensions not exceeding 50cm)
•

3. Advantages and Characteristics

• High Reliability: It has a strong anti-interference ability, which can ensure the stability and accuracy of data transmission in harsh industrial electromagnetic environments. The bit error rate is extremely low. For example, in the complex electromagnetic environment of some large factories, it can still guarantee the integrity of data transmission. In fact, in a large-scale manufacturing plant, the bit error rate of data transmission using TC514V2 is less than 0.0001%.
• Easy Integration: Its compact design makes it easy to install in various control cabinets or equipment. It can be easily integrated into existing industrial automation systems, reducing installation space and wiring costs. In a retrofitting project of an old factory’s automation system, TC514V2 was installed without any major modifications to the existing layout, saving a significant amount of installation time and cost.
• Wide Operating Range: It has a wide operating temperature range and can adapt to different temperature changes in industrial environments. Whether in the high-temperature environment of a steel plant or the low-temperature environment of a cold storage, it can operate stably. The operating temperature range is from -20°C to 60°C.

4. Application Areas and Application Cases

• Application Areas: Widely used in automation control systems in industries such as manufacturing, energy, chemical, and power. It is suitable for scenarios that require remote monitoring and data transmission, such as the monitoring of production lines in factories, remote monitoring of energy pipelines, and automation control of chemical production processes.
• Application Case: In a large automotive manufacturing factory’s automated production line, ABB’s TC514V2 was used to connect the control systems of various production links. By converting twisted pair signals into fiber optic signals, it achieved long-distance and high-speed data transmission between different workshops, ensuring precise control and efficient operation of the production process. As a result, the production efficiency was increased by 30%, and the product quality was significantly improved.

5. Comparison with Competitors

6. Selection Suggestions

• Compatibility: Ensure that the TC514V2 is compatible with the existing Advant Fieldbus 100 communication network and other related equipment. Check whether the communication protocols and interface types match.
• Installation Environment: Consider the size of the installation space, environmental temperature, humidity, and electromagnetic interference. Ensure that the module can work stably in a suitable environment. If the installation space is limited, the compact design of TC514V2 will be a great advantage.
• Budget: Consider the product price, maintenance cost, and performance comprehensively. Select a product with high cost-effectiveness while meeting the project requirements. Although TC514V2 may have a slightly higher initial cost, its long-term reliability and low maintenance cost make it a cost-effective choice in the long run.

7. Precautions

• Safety Regulations: When installing and operating the TC514V2, relevant electrical safety regulations must be followed. Ensure reliable grounding to avoid the risk of electric shock.
• Maintenance Suggestions: Regularly check whether the connections of the module are loose and whether the indicator lights are in normal status. Clean the surface of the module in a timely manner to remove dust and keep the module well-ventilated for heat dissipation. When upgrading the firmware, be sure to follow the operation guide provided by ABB to prevent errors during the upgrade process that may lead to module failures.
