ABB PE1315A

Description

ABB PE1315A is a multi-functional industrial automation module, its specific product description, parameters, specifications, series, features, functions, uses and application fields are as follows:

ABB PE1315A Product description

ABB PE1315A belongs to ABB’s PE series module and is a high-performance photoelectric isolation pulse amplifier module. It is mainly used in industrial automation control systems for signal isolation, amplification and shunt processing. The module adopts photoelectric coupler to realize electrical isolation between input and output, which has high reliability and stability, and is suitable for harsh environment.

Product parameter

Input voltage: 5-24V DC (some models support 100-240V AC).

Output voltage: 24V DC.

Current limit: Maximum 13mA.

Operating temperature range: -20°C to +60°C.

Storage temperature range: -40°C to +85°C.

Size: 70x70x12mm or 96x64x24mm (different models).

Protection class: IP20 or IP66 (some models).

Weight: About 225g.

Product specification

Number of channels: Usually 3 channels (A, B, Strobe), supporting simultaneous processing of multiple signals.

Response time: Rise time < 10μs, descent time < 10μs.

Accuracy: High signal processing accuracy, suitable for rapidly changing measurement signals.

Isolation voltage: up to 2500V.

series

ABB PE1315A belongs to the PE series of modules, which are known for their high performance, high reliability and compact design, and are widely used in industrial automation.

trait

High performance: Using high performance processor and FPGA technology to support fast response and real-time processing.

High reliability: Redundant design and strict quality control ensure the long-term stable operation of the module.

Easy to use: Intuitive configuration software and detailed documentation support are provided.

Multi-function integration: Support signal isolation, amplification, frequency division and other functions, suitable for a variety of industrial scenarios.

Modular design: Supports DIN rail installation for easy maintenance and expansion.

effect

The main role of ABB PE1315A is to process pulse signals, including signal isolation, amplification and shunt. It can effectively improve the anti-interference ability of the system, and ensure the stability and accuracy of signal transmission.

use

ABB PE1315A is widely used in the following areas:

Industrial automation control system: used for servo motor control, stepper motor control, valve control, etc.

Mechanical manufacturing: For precise control of servo drives and stepper motors.

Electronics industry: for signal isolation and processing.

Laboratory and test measuring equipment: for signal shaping and amplification.

Instrumentation: used for sensor signal acquisition and processing.

Application field

Applications for ABB PE1315A include, but are not limited to:

Manufacturing: such as production line automation, assembly robots, etc.

Energy industry: for example, signal processing in power systems.

Logistics and transportation: e.g. conveyor belt speed monitoring.

Medical equipment: for signal processing and control.

Building automation: for data acquisition and control.
