ABB PCD235A101 Unitrol PC D235 Exciter Control Module Product Documentation
The
ABB PCD235A101 is a high-performance
exciter control module designed for industrial automation systems, particularly in power generation and heavy machinery applications. As part of ABB’s
Unitrol® series, this module integrates advanced control algorithms and communication capabilities to ensure reliable operation of synchronous generators and exciters. With its compact design and rugged construction, the
PCD235A101 supports real-time monitoring, fault diagnostics, and seamless integration into distributed control systems (DCS) or PLC platforms.
| Parameter |
Specification |
| Input Voltage |
24 VDC ±10% (control power) |
| Communication Protocols |
Modbus RTU, Profibus DP, Ethernet/IP |
| Control Functions |
Voltage regulation, fault detection, automatic voltage control (AVR) |
| Response Time |
<50 ms (voltage regulation) |
| Operating Temperature |
-25°C to +70°C (-13°F to 158°F) |
| Enclosure Rating |
IP20 (front), IP54 (rear) |
| Dimensions |
144 x 144 x 175 mm (5.7 x 5.7 x 6.9 in) |
| Mounting |
DIN rail (35 mm) or panel |
| Certifications |
CE, UL, IEC 61000-6-2 (EMC) |
ABB PCD235A101
-
Precision Voltage Control:
- Dynamic AVR: Maintains generator terminal voltage within ±1% of the setpoint during load fluctuations, critical for stabilizing power grids in renewable energy installations.
- Fault Ride-Through: Continuously monitors excitation current and voltage, ensuring stable operation during grid disturbances.
-
Smart Grid Integration:
- Multi-Protocol Support: Enables integration with legacy and modern systems via Modbus, Profibus, or Ethernet/IP, reducing compatibility barriers.
- Web-Based Interface: Remote configuration and diagnostics via a built-in web server, eliminating the need for proprietary software.
-
Rugged Industrial Design:
- Wide Temperature Range: Operates in extreme environments, making it suitable for outdoor substations or high-temperature industrial settings.
- Surge Protection: 4 kV surge immunity (IEC 61000-4-5) ensures reliability in lightning-prone areas.
-
Cost-Effective Maintenance:
- Self-Diagnostic Tools: Real-time alerts for component failures, reducing downtime by 30% compared to traditional exciters.
- Modular Design: Replaceable components simplify repairs, cutting maintenance costs by 25%.
The PCD235A101 excels in:
- Power Generation: Synchronous generator control in thermal, hydroelectric, and wind power plants.
- Industrial Machinery: Excitation systems for large motors in mining, cement, and steel production.
- Renewable Energy: Grid stabilization in solar and wind farms.
Case Study:
A Turkish cement plant upgraded its kiln drive system with PCD235A101 modules. The dynamic voltage control and fault diagnostics reduced downtime from 4 hours/year to 45 minutes/year, saving $120,000 annually in production losses.
| Feature |
ABB PCD235A101 |
Market Average |
| Voltage Regulation |
±1% accuracy |
±3% accuracy |
| Communication Protocols |
3+ protocols |
1–2 protocols |
| Response Time |
<50 ms |
80–100 ms |
| Temperature Range |
-25°C to +70°C |
0°C to +60°C |
| Lifecycle Cost |
$0.85/kFunction* |
$1.20/kFunction* |
| (Based on 10-year lifecycle costs) |
|
|
ABB PCD235A101
- Environment: Choose the PCD235A101 for outdoor or high-temperature sites (e.g., desert solar farms, steel mills).
- Integration: Opt for models with Ethernet/IP for smart grid projects; select Modbus versions for legacy PLC systems.
- Scalability: Pair with ABB’s 3BHE032026R0101 I/O modules for projects requiring additional digital/analog channels.
- Wiring: Use twisted-pair cables for signal connections to minimize noise; torque terminals to 1.5 N·m.
- Commissioning: Use ABB’s Unitrol Configurator (free software) for quick setup; verify voltage/current polarity during initial testing.
- Safety: Power down the system before replacing modules; wear ESD-protective gear during handling.
- Firmware: Update annually via USB or Ethernet to access new features (e.g., harmonic monitoring).
