Description
ABB DYPS154C 61430001-YP is a high-reliability DC power supply module designed for industrial automation systems, providing stable and efficient power distribution for controllers, I/O modules, and field devices. Engineered by ABB, this module ensures uninterrupted operation in harsh industrial environments by delivering regulated 24 V DC power with advanced fault protection. DYPS154C 61430001-YP features a compact design, hot-swap capability, and support for redundant configurations, making it ideal for critical applications in manufacturing, energy, and process control. Its intelligent diagnostics and wide input voltage range enhance system availability and reduce maintenance downtime.
| Parameter |
Specification |
| Input Voltage |
19.2–30 V DC (nominal 24 V DC) |
| Output Voltage |
24 V DC (adjustable ±1%) |
| Rated Output Current |
10 A (peak 15 A for ≤5 seconds) |
| Efficiency |
≥90% at full load |
| Isolation |
Input/output isolation (500 V AC) |
| Redundancy Support |
Parallel redundancy with DYNR150 module |
| Operating Temperature |
-40°C to +70°C (no derating) |
| Mounting |
DIN rail (TS 35/7.5) |
| Dimensions (W×H×D) |
45 mm × 125 mm × 100 mm |
| Compatibility |
ABB AC 800M, Bailey INFI 90, and PLCnext |
DYPS154C 61430001-YP excels in reliability and flexibility. Its built-in overvoltage, overcurrent, and thermal protection mechanisms prevent damage from transient faults, with a mean time between failures (MTBF) exceeding 200,000 hours. The module’s hot-swap functionality allows replacement without system shutdown, reducing maintenance time by up to 50%. For example, in a chemical plant’s distributed control system (DCS), DYPS154C 61430001-YP maintained uninterrupted power during module replacement, avoiding a potential $10,000 loss from production downtime. Its redundant configuration capability (with DYNR150) ensures N+1 backup, eliminating single points of failure in critical systems.
Industry Applications:
- Manufacturing: Powering PLCs and robotics in automotive assembly lines.
- Energy: Stabilizing power for renewable energy inverters and substation automation.
- Process Control: Reliable power supply for valves, sensors, and safety systems in oil refineries.
Case Study: A food processing plant integrated DYPS154C 61430001-YP into its packaging line’s control system. The module’s wide temperature range (-40°C to +70°C) allowed stable operation in both cold storage areas and high-heat zones near sterilization equipment. Over one year, the plant reported a 30% reduction in power-related faults, improving overall equipment effectiveness (OEE) by 15%.
Compared to standard power supplies, DYPS154C 61430001-YP offers superior environmental resilience and system integration. Its ability to operate at full load from -40°C to +70°C outperforms many competitors that require derating above 50°C. The module’s native compatibility with ABB’s control ecosystem reduces wiring complexity by 30%, as it integrates seamlessly with AC 800M controllers without additional adapters, unlike non-ABB solutions.
- Power Requirements: Calculate total system load (including all devices) and ensure the module’s 10 A output provides a 20% margin for future expansion.
- Redundancy Needs: For critical applications, pair with DYNR150 to achieve redundant power supply, ensuring zero downtime during failures.
- Environmental Conditions: Prioritize this module for extreme temperatures or unstable power grids, as its wide input range and robust protection features minimize risks.
- Scalability: Use multiple modules in parallel for high-power systems, leveraging ABB’s modular design for easy expansion.
- Installation: Mount vertically in a ventilated control cabinet, leaving 50 mm clearance for heat dissipation; avoid direct sunlight.
- Wiring: Use stranded copper cables (≥1.5 mm²) for input/output; separate power and signal cables by 100 mm to reduce EMI.
- Redundancy Setup: When configuring parallel redundancy, ensure correct wiring via DYNR150 to prevent current backflow.
- Maintenance: Regularly inspect status LEDs (green for normal, red for fault) and clean dust from ventilation slots every 6 months to prevent overheating.
