Description

1. Product Description

The ABB CI627 acts as a bridge for industrial communication networks, supporting real-time data transfer across distributed control systems (DCS). Compatible with Advant Controller 110/160 and Advant Master platforms, it offers dual-channel High-Speed Link (HSL) for broadcast data transmission and AF100 protocol support for twisted-pair cable networks. Key functions include galvanic isolation via fiber optics, Ampl programming compatibility, and a compact DIN rail-mount design (128 mm × 98 mm × 43 mm). The module processes up to 1 Mbps data rates, ensuring fast response in applications like conveyor systems, power plants, and robotic assembly lines.

2. Product Parameters

Parameter Specification
Model CI627 (Family: Advant Master, Advant OCS)
Brand ABB
Protocol Support Profibus DP, DeviceNet, Modbus, AF100
Voltage DC 24 V (±10%)
Data Rate Up to 1 Mbps
Interfaces 2 × HSL (fiber optic), RS-485/RS-232
Dimensions 128 mm × 98 mm × 43 mm
Weight 0.4 kg
Operating Temperature -20°C to +55°C
Protection Class IP20
Certifications CE, UL, RoHS (exempted per 2011/65/EU)
ABB CI627

ABB CI627

3. Advantages and Features

  • Multi-Protocol Flexibility: Supports 4+ industrial protocols, reducing the need for additional gateway modules.
  • Rugged Design: Fiber optic isolation and IP20 protection ensure immunity to EMI and harsh conditions (vibration, dust).
  • Easy Integration: Hot-swap capability and plug-and-play design minimize installation time (≤30 minutes).
  • Scalability: Dual HSL channels enable expansion to 128+ nodes in distributed networks.
  • Reliability: 12-month warranty and 10+ year lifecycle, backed by ABB’s global support.

4. Application Fields and Cases

Industries: Manufacturing (automotive, food & beverage), energy (power generation), water treatment, and transportation.
Scenarios: Machine-to-machine communication, SCADA systems, and remote monitoring.



Case Study: A food processing plant integrated the CI627 to connect 50+ sensors and actuators across production lines. Its Profibus DP support and low latency (≤10 ms) reduced downtime by 25%, while fiber optic isolation eliminated signal interference, improving product quality by 15%.

5. Competitor Comparison

Compared to similar modules, the CI627 offers broader protocol support (4+ vs. 2–3 in comparable models) and faster data rates (1 Mbps vs. 0.5 Mbps). Its built-in AF100 compatibility reduces hardware costs by 20% (no external coupler needed), and its compact size saves 15% panel space.

ABB CI627

ABB CI627

6. Selection Recommendations

  • Compatibility: Ensure integration with ABB’s Advant Master/OCS systems; verify protocol requirements (e.g., Profibus DP for legacy devices).
  • Environment: Use fiber optic cables for long-distance (≤2 km) or high-EMI environments; avoid temperatures >55°C.
  • Scalability: Choose based on network size (HSL channels support up to 128 nodes).
  • Budget: New units (USD 2.2k–2.8k) vs. refurbished (USD 1.8k) with 12-month warranty.

7. Precautions

  • Installation: Secure DIN rail mounting; align connectors carefully to avoid pin damage.
  • Cabling: Use shielded twisted-pair (STP) cables for AF100; follow ABB’s wiring guidelines for fiber optics.
  • Software: Configure via ABB’s AMpl programming tool; update firmware regularly for security patches.
  • Maintenance: Monitor LED indicators (green: power; amber: fault); replace modules if signal loss persists.
Conclusion
The ABB CI627 is a versatile communication hub for industrial control systems, combining multi-protocol support, rugged reliability, and easy scalability. Ideal for mission-critical applications, it optimizes data flow while minimizing operational costs.
