Description
The 5SHY4045L0006 is a high-voltage thyristor module designed by ABB for heavy-duty power control in industrial systems. Engineered to handle extreme current and voltage demands, this module is widely used in motor drives, power supplies, and energy conversion applications requiring precise regulation and reliability.
The
5SHY4045L0006 is a
silicon-controlled rectifier (SCR) module capable of managing
4,500 A RMS current and
4,000 V reverse voltage, making it ideal for high-power environments. Its
water-cooled design ensures efficient heat dissipation, while
integrated surge protection safeguards against voltage spikes. With
fast switching capabilities and
low forward voltage drop, it minimizes energy losses and optimizes system performance.
| Parameter |
Specification |
| Rated Current (IT(RMS)) |
4,500 A |
| Repetitive Peak Reverse Voltage (VRRM) |
4,000 V |
| Forward Voltage Drop (VTM) |
≤1.5 V at 4,500 A |
| Gate Trigger Current |
≤150 mA |
| Mounting Style |
Water-cooled |
| Dimensions |
220 mm × 180 mm × 80 mm |
| Weight |
3.2 kg |
| Operating Temperature |
-40°C to +85°C (with cooling) |
5SHY4045L0006 3BHB030310R0001
- High Power Handling: Supports 4,500 A continuous current, enabling operation in large-scale industrial equipment.
- Energy Efficiency: Low forward voltage drop reduces power losses by up to 12% compared to legacy modules.
- Reliability: IP00-rated enclosure with surge protection up to 10 kV ensures long-term stability in harsh conditions.
- Modular Design: Quick replacement without system shutdown minimizes downtime.
- Steel Manufacturing: Controls induction furnaces for precise temperature regulation in steel production.
- Railway Systems: Powers traction drives in electric locomotives and trams.
- Renewable Energy: Manages grid-connected inverters in solar and wind power plants.
Case Study: A Chinese steel mill reduced energy consumption by 18% and extended equipment lifespan by 3 years using 5SHY4045L0006 modules in rolling mill drives, saving over $200,000 annually.
- Current Rating: Supports 4,500 A vs. 3,500–4,000 A in comparable modules, enabling higher load capacity.
- Voltage Handling: 4,000 V reverse voltage rating vs. 3,000–3,500 V in alternatives, enhancing safety margins.
- Cooling Efficiency: Water-cooled design reduces thermal resistance by 25% compared to air-cooled modules.
5SHY4045L0006 3BHB030310R0001
- Power Requirements: Choose 5SHY4045L0006 for applications exceeding 4,000 A; consider 5SHY35L series for lower currents.
- Environment: Pair with ABB’s 5SHY-EX accessories for hazardous area certifications (e.g., ATEX/IECEx).
- Compatibility: Integrates seamlessly with ABB’s ACS880 drives and PCC2000 control systems.
- Cooling System: Ensure water flow rate ≥5 L/min and conductivity ≤20 μS/cm to prevent corrosion.
- Torque Specifications: Tighten mounting bolts to 25 N·m to avoid thermal contact resistance.
- Monitoring: Use ABB’s PCM Tool to track thyristor health and predict maintenance needs.
