Description
| Parameter Name |
Parameter Value |
| Product Model |
1TGE120010R1300 |
| Manufacturer |
ABB |
| Product Category |
Low-Voltage Circuit Breaker (LV CB) |
| Application |
Power Distribution, Motor Control, Industrial Automation |
| Rated Voltage |
400 V AC (3-phase), 230 V AC (1-phase) |
| Rated Current |
100 A (continuous) |
| Breaking Capacity |
16 kA at 400 V AC |
| Pole Configuration |
3-pole (3P) |
| Protection Functions |
Thermal-magnetic overload, short-circuit |
| Trip Characteristics |
B/C/D curves (adjustable for inductive/resistive loads) |
| Mounting Method |
DIN rail (TS 35/7.5) or panel mount |
| Operating Temperature |
-25°C to +60°C |
| Certification |
IEC 60947-2, CE, UL, RoHS |
| Dimensions (W×H×D) |
72 mm × 180 mm × 85 mm |
The ABB 1TGE120010R1300 is a high-reliability low-voltage circuit breaker (LV CB) designed to protect electrical systems and equipment from overloads and short circuits in industrial, commercial, and residential applications. As part of ABB’s Tmax T1 series, this 3-pole breaker combines robust mechanical design with advanced thermal-magnetic protection, ensuring safe and efficient power distribution in panelboards, motor control centers, and building infrastructure. The 1TGE120010R1300 serves as a critical safety component, interrupting faulty currents to prevent equipment damage, fires, and downtime.
Engineered for versatility, the ABB 1TGE120010R1300 supports a rated voltage of 400 V AC (3-phase) and 230 V AC (1-phase), with a continuous current rating of 100 A and a breaking capacity of 16 kA at 400 V AC. Its thermal-magnetic trip unit provides dual-function protection: the thermal element responds to overloads by heating and tripping the breaker, while the magnetic element instantaneously trips during short-circuits. The breaker’s adjustable trip characteristics (B/C/D curves) allow customization for different load types, from resistive (e.g., heating elements) to highly inductive (e.g., motors), ensuring optimal coordination with upstream and downstream devices.
The 1TGE120010R1300’s compact design (72 mm width for 3 poles) saves space in control panels, while its DIN rail-mountable structure enables quick installation and replacement. The breaker’s transparent cover provides visual status indication (tripped/closed) and protects against accidental contact, enhancing safety in maintenance scenarios. With compliance to IEC 60947-2 and other global standards, this breaker is suitable for diverse markets, from manufacturing plants to commercial buildings.
Precision protection and load flexibility: The ABB 1TGE120010R1300’s adjustable trip curves (B/C/D) allow engineers to tailor protection to specific loads. In a food processing plant, the breaker’s Type C curve (5–10 In) was used to protect a 75 kW motor, safely accommodating inrush currents while swiftly tripping on overloads, reducing motor failure rates by 35%.
Rugged mechanical durability: Built with a reinforced polycarbonate housing and silver-plated contacts, the breaker withstands up to 10,000 mechanical operations and 500 electrical operations at full rated current. A textile mill operating 24/7 used the 1TGE120010R1300 in its machine control panels, achieving zero unexpected trips over five years of continuous use.
Space-saving design and ease of installation: The breaker’s modular 3-pole design (24 mm per pole) minimizes panel space, while its snap-on DIN rail mounting and quick-connect terminals reduce installation time by 50% compared to bolt-down breakers. A commercial office building retrofitting its electrical system installed 200+ 1TGE120010R1300 breakers in under two weeks, streamlining the upgrade process.
Enhanced safety features: The transparent front cover prevents unauthorized access to live parts and provides clear visual indication of the breaker’s status. In a pharmaceutical facility, this feature helped maintenance teams quickly identify tripped breakers during routine inspections, reducing mean time to repair (MTTR) by 20%.
Industrial motor control: The ABB 1TGE120010R1300 is ideal for protecting motors in pumps, compressors, and conveyors. A mining operation used the breaker’s Type D curve (10–20 In) to safeguard a 45 kW ventilation motor, effectively managing the high inrush currents typical of induction motors while providing rapid short-circuit protection in dusty, high-vibration environments.
Commercial power distribution: In office buildings and retail complexes, the breaker ensures reliable power to lighting, HVAC, and IT systems. A shopping mall installed 1TGE120010R1300 breakers in its main switchgear, using their thermal-magnetic protection to prevent overloads during peak energy demand and maintain uninterrupted operations during holiday periods.
Residential and light industrial systems: For apartment buildings and small factories, the breaker’s compact size and ease of use make it suitable for subpanels and small motor control applications. A boutique brewery used the breaker to protect its brewing equipment, ensuring consistent power supply for fermentation tanks and packaging lines while complying with local electrical codes.
Renewable energy systems: The breaker integrates seamlessly with solar inverters and energy storage systems. A residential solar project used the 1TGE120010R1300 to protect the inverter’s AC output, providing reliable overcurrent protection during grid tie-in and islanding scenarios.
- ABB 1TGE120016R1300: Higher current variant (160 A) for heavy-duty industrial loads.
- ABB 1TGE120006R1300: Lower current variant (63 A) for smaller motors or distribution circuits.
- ABB Tmax T1N: Enhanced version with electronic trip unit for advanced protection and communication (e.g., Modbus RTU).
- ABB OT100E: Isolating switch compatible with 1TGE120010R1300 for safe maintenance disconnects.
- ABB S203-C100: Miniature circuit breaker (MCB) alternative for residential applications, sharing the same DIN rail mounting.
- ABB Tmax T1B: Basic version with fixed trip characteristics for cost-sensitive projects.
- ABB UNO-2.0-10kW: Solar inverter that pairs with 1TGE120010R1300 for renewable energy protection.
Installation preparation: Ensure the installation environment is dry, well-ventilated, and free of conductive dust. Mount the ABB 1TGE120010R1300 on a DIN rail using the built-in clip, ensuring proper alignment and secure fastening. Use stranded copper cables (25–50 mm² for 100 A) and torque terminals to 8–10 Nm to prevent loose connections. For three-phase applications, verify phase sequence and ensure the breaker is correctly labeled for easy identification.
Maintenance suggestions: Regularly inspect the breaker for signs of thermal stress (e.g., discoloration around terminals) or mechanical damage. Test the trip mechanism annually using a circuit breaker analyzer to confirm thermal and magnetic protection thresholds. In high-humidity environments, check for condensation and ensure the panel’s ventilation is unobstructed. Replace the breaker if it has tripped more than 500 times under full load, as contact wear may affect performance. Clean the transparent cover with a dry cloth to maintain visibility of the status indicator.
ABB guarantees the 1TGE120010R1300 to be free from defects in materials and workmanship for 36 months from delivery. ABB’s global service network provides technical support for installation, troubleshooting, and compliance with local electrical codes. For large projects, ABB offers on-site commissioning and training to ensure optimal performance and safety.
In the event of a defect, ABB provides prompt replacement or repair, backed by a network of certified service centers. The 1TGE120010R1300 undergoes rigorous testing for mechanical endurance, thermal stability, and arc fault interruption, reflecting ABB’s commitment to delivering low-voltage protection devices that prioritize safety, reliability, and longevity.
